Home > Products > Kettle & Tank > Multifunctional industrial Vessel with Coil
Multifunctional industrial Vessel with Coil
- 20 Set / Sets per Month
- Shanghai
- T/T
Product Details
| Condition: | New | Automatic Grade: | Automatic | Type: | Tank Reactor |
| Place of Origin: | Shanghai, China | Brand Name: | SIEHE | Model Number: | SJBF |
| Voltage: | 220V or 380V, or customized | Power(W): | 380~440V/3Phase/50Hz | Dimension(L*W*H): | 500mm*500mm*2000mm ~ 3500mm*3500mm*8000mm |
| Weight: | 200kg ~ 7500kg | Certification: | CE, ISO, SGS, ISO9001 | Warranty: | 12 months |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Multifunctional industrial Vessel with Coil
Reactor is a kind of atmospheric pressure or pressure vessel that is applicable for petroleum, chemical, rubber, pesticide, dyestuff, medicine, food and other industries, and used to complete the process of vulcanization, nitration,hydrogenation, alkylation, polymerization, condensation, also called polymerization reaction kettle, reactor, decomposition kettle, etc.; the material usually adopts carbon manganese steel, stainless steel, zirconium, nickel based (Harrington, Meng Naier, Kang Nie) alloy and other composite materials. Siehe company mainly produce the stainless steel reactor and carbon manganese steel reactor.
[Material Viscosity]: ≤500,000 cps
[Production Capacity]: 50-50,000L
[Application]Applicable for the dispersing and mixing of chemical, biological, lubricating oil, all kinds of resin and derivative products industries.
[Applicable Material]:viscosity under 500,000cps, solid content under 60%, various paste and liquid materials such as resin, adhesive, pesticide and biology, etc.
Model | Power(kw) | Speed | Agitator | Equipment Material | Capacity | Weight(kg) |
SJBF-1.1 | 1.1 | 100rpm | Anchor type, paddle type, frame type and other types of agitators don’t share the same data regarding the viscosity application, speed, power, etc. | alloy steel/SS304/SS316L | ≤0.2 | 250 |
SJBF-1.5 | 1.5 | 85rpm | alloy steel/SS304/SS316L | ≤300 | 250 | |
SJBF-2.2 | 2.2 | 76rpm | alloy steel/SS304/SS316L | ≤500 | 300 | |
SJBF-3.0 | 3.0 | 67rpm | alloy steel/SS304/SS316L | ≤800 | 350 | |
SJBF-4.0 | 4.0 | 63rpm | alloy steel/SS304/SS316L | ≤1000 | 450 | |
SJBF-5.5 | 5.5 | 59rpm | alloy steel/SS304/SS316L | ≤1500 | 350 | |
SJBF-7.5 | 7.5 | 59rpm | alloy steel/SS304/SS316L | ≤2500 | 450 | |
SJBF-11 | 11 | 53rpm | alloy steel/SS304/SS316L | ≤3000 | 350 | |
SJBF-15 | 15 | 53rpm | alloy steel/SS304/SS316L | ≤4000 | 450 | |
SJBF-18.5 | 18.5 | 53rpm | alloy steel/SS304/SS316L | ≤5000 | 350 | |
SJBF-22 | 22 | 43rpm | alloy steel/SS304/SS316L | ≤8000 | 450 | |
SJBF-30 | 30 | 43rpm | alloy steel/SS304/SS316L | ≤10000 | 350 | |
… |
|
|
|
|
|
|
SJBF-200 | 200 | customized | customized | alloy steel/SS304/SS316L | customized | customized |
Remark:
* The agitator type and power can only be confirmed after knowing materials state, viscosity and mixing effect;
* Equipment material should be chose according to the corrosive property of the mixture; carbon steel, SS316L or spray coating are for option;
* The above-listed capacity data is calculated based on 2,000cps material, when selecting a model, the actual viscosity and specific gravity should be considered.
* The above-listed data of equipment weight does not contain the kettle/tank weight, and also relates to the agitator type and material viscosity.
* This table does not include all models, for more information, please contact with our sales engineer.
Product Advantages
- All-in-one Design with Heating, Cooling, Dust Collecting and Condensing
Siehe industry has many years’ experience of reactor application, and capable of realizing the functions of heating, cooling, thermal insulation, mixing reacting, dust collecting and condensing & refluxing within one reactor, meet the requirement of high integration, improve the production efficiency and reduce the cost.
- Diverse Structure
Siehe reactor, according to structure, can be divided into: open flat cover type, open flange type and closed type;
According to pressure, can be divided into: atmospheric pressure type, negative pressure type, positive pressure type, positive and negative pressure type;
According to heating and cooling mode, can be divided into: jacketed type, coil pipe type, outer jacket and inner coil pipe type, inner and outer coil pipe type;
The agitator type is diverse, according to the materials feature;
- Non-Standard Customizing, Complete Production Line Designing
Usually design the complete production line according to the output, production process, processing time, etc.
SIEHE Industry----Mixing Experts on Liquid and Powder!
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
Skype: siehe.sales10
