100W Universal Laptop Power Charger Adapter

Specifications

100W Laptop Universal Adaptor
1.Input:110V-240V or DC12-16V
2.Output:12-24V 100W
3.Use for:Laptop,LCD monitor
4.MOQ:100pcs

100W Universal Laptop Power Charger Adapter



Descriptions:

- It comes with 8 separate tips to fit almost any laptop.
- Accepts input 110V-240V 50-60Hz, allowing worldwide usage.
- With USB port for charge USB devices
- Stabilized output, low ripple & low interference
- Adjustable output voltage
- Power LED Monitor



Technical Parameter:



Output Voltage:	DC 12/15/16/18/20/22/24V
Output Current:	DC 12/15/16/18/20V 5.5A  Max
	DC 22/24V  4.0A Max
Output Power:	100W
Rated Input voltage:	AC 110-240V or DC 12V
Input frequency:	50/60Hz
Vibration Input Voltage Range:	AC100-240V or DC10.5-15V
Vibration Input Frequency Range:	45/65Hz
Input Current:	1.8A max
Input Current:	0.1A min
Efficiency:	>88% (TYP)
USB Connection:	Yes(5V/1A)
Overload Protection:	Yes
Overvoltage Protection:	Yes
Short Circuit Protection:	Yes
Line loss:	1%
Dimensions (L x W x H):	113mm*64.0mm*25.0mm
Net Weight:	550g
Package:	Vacuum-Thermoform or Color Box
Standard:	CE  FCC  ROHS
Warranty:	1 Year



8 Detachable Connectors:



• 6.0mm*1.0mm
• 6.3mm*3.0mm
• 5.5mm*2.5mm
• 5.5mm*2.1mm
• 5.5mm*1.7mm
• 4.8mm*1.7mm
• 4.0mm*1.7mm
• 3.5mm*1.35mm





Compatibility:



* Acer (Aspire, Tablet, Travelmate, AcerNote, Anywhere, Extensa, AcerNoteLight)
* AMS Tech (Rodeo, TravelPro, AVERATEC)
* Compaq (Armada, LTE, Evo, Presario, Prosignia, Tablet)
* Fujitsu ( LifeBook models)
* Gateway
* HP (Pavilion, Omnibook)
* IBM ( Most ThinkPad models)
* NEC (LaVie C, LC series, PC Series, LT series)
* Versa (VersaNote, VersaPro)
* Panasonic(Toughbook models)
* Sharp
* Sony Picturebook
* SONY VIAO
* Sotec
* Toshiba (Satellite, Dynabook Satellite Pro, Dynabook Satellite

* Libretto, Portege, SatellitePro, Tecra)
* Winbook
* Dell Inspiron
(1100, 2500, 2600, 2650, 3700, 3800, 4000, 4100, 4150, 5000, 5000e, 5100, 7500, 8000, 8100, and 8200) + Mini 9, 10 and 12
* Dell Latitude
(CP, CPi, CPi A, CPi R, CPt C, CPt S, CPt V, CPx H, CPx J, CS R, CSx H, C400, C500, C510, C600, C610, C640, C800, C810 and C840 )





Package Included:
1 X New Universal car and home adaptor for laptop with USB Port
8 X Laptop Adapter's Connector
1 X US Power Cord
