High Current Terminal Blocks

FOB Price

Negotiable / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Guangdong, China

Brand Name:

SCED

Model Number:

TR15-00-FaM0

Parameter and Drawing Specifications:

UL Technical Data	B	C	D
Rated Voltage / Current V/A	600 / 15	600 / 15
Wire Range AWG	14-24	14-24
IEC Technical Data
Overvoltage Category	Ⅲ	Ⅲ	Ⅱ
Contamination Class	3	2	2
Rated Voltage / Current V/A	800 / 15	1000 /15	1000 / 15
Rated Surge Voltage KV	8	8	8
Rated Connecting Capacity mm²	1.25
Material
Insulation Material / Inflammability Class	PC / UL94, V-0
Conduction Board/ Plating	Brass /Nickel Plated
Screw / Plating	Steel / Zinc Plated
Other Data
Stripping Length mm	8-9
Screw Torque mm	M3.5 /7-10
