API grade oil drilling starch machine

Specifications

Modified starch processing line
1. Twin screw extruder
2. oil drilling starch, Pre-gelatinized starch

Modified Starch Processing Line/Oil Drilling Starch Machines

1. Description:

The modified starch processing line  is researched and developed by our company based on the foreign advanced technology. This processing line can denaturant the starch of the raw grains and be in favor of the adsorption. It has the higher nutrition than the traditional craft. The screws are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully. The forced lubrication system, by guaranteed equipment transmission longer life. Visible auto-temperature controlling system, make the temperature-controlling to be more direct-viewing, parameter to be more precise.



2. Raw materials: corn starch, cassava starch, potato starch



3. Products: oil drilling starch, Pre-gelatinized starch



4. Capacity: 500kg/h, 1ton/h, 2ton/h



5. Flow Chart: Mixing---Extrusion---Drying---Grinding---Blending—Packing



6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries



7. Machines Materials: All the machines are made by stainless steel



8. Technical Parameters

Model	Installed power	Real power	Output	Dimension
AMC85	145kw	100kw	300-400kg/h	20000x2000x3500mm
AMC90	135kw	90kw	600-800kg/h	22000x2000x3500mm
AMC120	155kw	110kw	1500-2000kg/h	24000x3500x4500mm
AMC130	235kw	165kw	2000-3000kg/h	30000x3500x4500mm



9. Samples pictures
