rental P6 indoor led advertising screen

number

Item name

Parameter and index

unit module

1

LED encapsulation mode

SMD 3528 Surface mounted

2

Horizontal axis

160°

3

Vertical axis

160°

4

Pixel composition

1R1G1B

5

Pixel pitch

6mm

6

Scan method

1/8 Scan

7

Drive method

Constant current

8

Module resolution

32pixel× 32pixel

9

Module dimensions

192mmx192mm

10

Module type

Synergetic lamp and drive

11

Module working voltage

+5V

12

Average Power Consumption

6.25W

13

Cabinet Maximum Power Consumption

25W

14

Module shell material

PC

15

Module mask material

PC

unit cabinet

1

Module layout

4×4 pieces

2

Cabinet resolution

128pixel× 128pixel

3

Cabinet maximum power

400W

4

Cabinet average power

100W

5

Cabinet dimension

768mm×768mm

6

Cabinet material

steel/aluminum alloy

7

Cabinet color

black/gray

Entire screen

1

Application environment

indoor

2

White balance brightness

>1800cd/sqm

3

White balance coordinates

X=0.29,Y=0.31

4

contrast

64000:1

5

Color temperature

8000K

6

Pixel density(pixels/sqm)

27777

7

Average consumption(W/sqm)

212

8

Maximum consumption(W/sqm)

848

9

Power source

AC220V/50HZ or AC110V/60HZ

10

Operating temperature

-10°C~ +45°C

11

Operating humidity

10%~90%

12

Storage humidity

-30°C ~ +50°C

13

Refresh frame rate

60Hz

14

Refresh rate

480Hz

15

Viewing distance

6-100m

16

grayscale/color

16.7M

17

Brightness adjustment

100 manual levels /100 auto levels

18

Control method

synchronous with the computer display

19

signal transfer distance

Network cable:100m

20

Computer operating system

WINDOWS(98,2000,XP,Vista,7)

21

Video signal

VGA,DVI,RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION and so on.

22

MTBF

≥10000 hours

23

Longevity

≥100000 hours

24

Certification

UL/CE/CCC
