Atv 150 cc

Specifications

Features:

MODEL TYPE: Madix 150

1) Engine: 150cc, 4-stroke, single cylinder, air cooled

2) Engine displacement (ml): 147

3) Bore x stroke (mm): 52 x 49.5

4) Max. power (km/r/min): 8.5/8,000

5) Max. Torque(r/min): 7/6,000

6) Minimum fuel consumption (g/kW.h): 367

7) Starting mode: electric start

8) Transmission mode: chain driven

9) Brake type (front/rear): disc/disc

10) Brake distance (m/30km): 7

11) Shift speed type: four with reverse gear

12) Clutch mode: manual clutch

13) Minimum turning radius (mm): 3,000

14) Climbing degree: 27

15) Seat height (mm): 670

16) Minimum ground clearance (mm): 120

17) Top speed (km/h): 55

18) Tire dimension (front/rear): AT18 x 9.5-8/AT18 x 9.5-8

19) Cover material: PP

20) Available colors:white, black, orange

21) Product dimensions: 1,610 x 1,050 x 1,160mm

22) Dual "A" arm swingPacking:Carton dimensions: 1,480 x 860 x 760mm

N.W.: 130kg

G.W.: 155kg

Conveyance:

Qty/20' FCL: 39pcs

Qty/40' HQ: 112pcs
