Home > Products > 07.Pillow Block Bearing > SAIFAN Bearing UCF326 Pillow Block Bearing UC326 Insert Ball Bearing

SAIFAN Bearing UCF326 Pillow Block Bearing UC326 Insert Ball Bearing

FOB Price

USD $6.89 - $30.85 / Set

1 Set(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port Qingdao Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Bore Size:	10, 400	Brand Name:	SAIFAN OR OEM	Model Number:	UCF326
Place of Origin:	Shandong, China

Product Description

SAIFAN Bearing UCF326 Pillow Block Bearing UC326 Insert Ball Bearing

Bearing UCF326 Details

Brand	UCF326 Pillow Block Bearing F204
Item	SAIFAN Bearing UCF326 Pillow Block Bearing UC326 Insert Ball Bearing
Ball Bearing seals	ZZ 2RS
Material	GCr15 steel,carbon steel,stainless steel etc.
Precision	P0,P2,P5,P6,P4
Clearance	C0,C2,C3,C4,C5
Bore size	0-200 mm	outer diameter	0-400mm
Cage type	brass;steel plate,nylon,aluminium alloy etc.
Seal type	open,sealed(ZZ,RS,2RS)
Bearings Feature	Long-life with high quality
	Low-nosie with strict controlling the quality of SaiFan bearing
	High-load by the advanced high-technical design
	Competitive price, which has the most valuable
	OEM service offered, to meet the customers'requirements
Application	gearbox,auto,reduction box,engine machinery,mining machinery,bicycles,etc Insert Bearing Units With Housing
Bearing Package	Pallet,wooden case,commercial packaging or as customers' requirement.
Price terms	FOB,CFR,CIF,EXW	delivery time	3-5 days acccording the quantity

UCF326 Pillow Block Bearing Photos

1.Specifications :

Saifan Pillow Block Bearing UCF or NP Series Plummer / Pillow Housings: Supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing

2.Application :

Economical housed bearing solution

Light and heavy industrial use Pillow Block Bearing
Agricultural and Automotive Pillow Block Bearing
Conveyor and Fan assemblies Pillow Block Bearing
Fabricated machine assembly Pillow Block Bearing
Great value quality parts dispatched the same day

3.Features :

1. With tight set screw insert class UC bearing Pillow Block Bearing ;
2. Insert UK type bearing with conical hole;
Pillow block bearing is deep groove ball bearing grease seal type bearing with different shapes and combination of high precision components products.Bearing assembly can pass a few bolts to install directly on the body of the mechanical device, with the heart function, can be the supplement of the grease, etc., is a kind of installation is very simple products.

Pillow block bearingUSES: outer spherical bearing is suitable for the required equipment and parts of simple situation, such as used for agricultural machinery, transportation systems or on construction machinery

4.UC326 Insert Ball Bearing Related Pillow Block Bearing Catalogue:

SAIFAN Bearing UCF326 Pillow Block Bearing UC326 Insert Ball Bearing

Model NO.	Length(mm)	Width(mm)	Thickness(mm)	Weight(kg)
UCF201 Bearing	127	38	60.7	0.760
UCF202 Bearing	127	38	60.7	0.740
UCF203 Bearing	127	38	60.7	0.720
UCF204 Bearing	127	38	64	0.700
UCF205 Bearing	140	38	69.5	0.760
UCF206 Bearing	160	44	82	1.250
UCF207 Bearing	167	48	92	1.550
UCF208 Bearing	180	52	98	1.900
UCF209 Bearing	189	54	106	2.200
UCF210 Bearing	204	57	112	2.750
UCF211 Bearing	217	60	125	3.300
UCF212 Bearing	238	66	137	4.700
UCF213 Bearing	262	70	149	5.600
UCF214 Bearing	266	72	155	6.600
UCF215 Bearing	274	74	162	7.300
UCF216 Bearing	292	78	174	9.000
UCF217 Bearing	310	83	186	10.80
UCF218 Bearing	326	88	198	13.00
UCF220 Bearing	380	95	225	16.00
UCF305 Bearing	175	45	85	1.400
UCF306 Bearing	180	50	95	1.800
UCF307 Bearing	210	56	106	2.800
UCF308 Bearing	220	60	116	3.080
UCF309 Bearing	245	67	129	4.100
UCF310 Bearing	275	75	143	6.000
UCF311 Bearing	310	80	154	7.400
UCF312 Bearing	330	85	165	9.400
UCF313 Bearing	340	90	176	10.000
UCF314 Bearing	360	90	187	12.000
UCF315 Bearing	380	100	198	14.000
UCF316 Bearing	400	110	210	18.000
UCF317 Bearing	420	110	220	20.000
UCF318 Bearing	430	110	220	24.000
UCF319 Bearing	470	120	250	26.500
UCF320 Bearing	490	120	275	34.300
UCF321 Bearing	490	120	280	36.600
UCF322 Bearing	520	140	300	42.500
UCF324 Bearing	570	140	320	53.500
UCF326 Bearing	600	140	355	72.100
UCF328 Bearing	620	140	390	89.100

SaiFan Advantage
SOLUTION – At the beginning, we will have a communication with our customers on their demand, then our engineers will work out an optimum solution based on the customers’ demand and condition. PRODUCTION – Running in accordance with ISO 9001 quality system, the advanced production equipments, sophisticated processing technology, strict quality management system, skilled workers and innovative technical team, make our bearings in continuous quality improvement & technology development. QUALITY CONTROL (Q/C) - In accordance with ISO standards, we have professional Q/C staff, precision testing instruments and internal inspection system, the quality control is implemented in every process from material receiving to products packaging to ensure our bearings quality. PACKAGE – Standardized export packing and environment-protected packing material are used for our bearings, the custom boxes, labels, barcodes etc. can also be provided according to our customer’s request. LOGISTIC – Normally, our bearings will be sent to the customers by ocean transportation due to its heavy weight, airfreight, express is also available if our customers need. WARRANTY – We warrant our bearings to be free from defects in material and workmanship for a 12 months period from the shipping date, this warranty is voided by non-recommended use, improper installation or physical damage.
About US
				High Quality Bearings, Choose Saifan. Jinan Saifan Bearing Co., Ltd is a professional bearing manufacture located in Jinan, Shandong. We are established in year 2005 and we have 10 years experience in bearing manufacture. We mainly produce wheel hub bearings, ball bearings, roller bearings etc.
Our Workshop

Production

Saifan Exhibition

Express & Payment

FAQ
Q:What’s your after-sales service and warranty? A: We promise to bear the following responsibility when defective product is found: 1.12 months warranty from the first day of receiving goods; 2. Replacements would be sent with goods of your next order; 3. Refund for defective products if customers require. Q:Do you accept ODM&OEM orders? A: Yes, we provide ODM&OEM services to worldwide customers, we are able to customize housings in different styles, and sizes in different brands, we also customize circuit board & packaging box as per your requirements. Q:What’s the MOQ? A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders. Q:How long is the lead time? A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days. Q:Do you offer free samples? A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight. We DO NOT offer free samples to end users. Q:How to place orders? A: 1. Email us the model, brand and quantity, consignee information, shipping way and payment terms; 2. Proforma Invoice made and sent to you; 3. Complete Payment after confirming the PI; 4. Confirm Payment and arrange production.
