Home > Products > Thermal Grease > Hot Sale High Thermal Conductivity Silicone Grease for LED/CPU/VGA heat sink
Hot Sale High Thermal Conductivity Silicone Grease for LED/CPU/VGA heat sink
- 5000 Kilogram / Kilograms per Month
- shenzhen Guangzhou
- Credit Card
- Environmental and Safety Led Light/Electronics Heat Sink Thermal Grease For Notebook And Desktop PCs
- Compliance With Rohs Directive Cpu Heat Sink Thermal Grease For Computer Services
- Non-Corrosive Led Heat Sink Thermal Grease For Notebook And Desktop PCs
- Non-Corrosive Heat Sink Thermal Grease For Notebook And Desktop PCs
- Never Be Dried Thermally Conductive Silicone Grease For Audio And Video Component
- Hot sale non corrosive silicone grease with good thermal conductivity performance
Product Details
Other Names: | Thermal Silicone Grease | Place of Origin: | Guangdong, China | Classification: | Other Adhesives |
Main Raw Material: | Silicone | Usage: | Other, LED light,High frequency microprocessors,Notebook and desktop PC | Brand Name: | Sheen |
Model Number: | SG560-12 |
Product Description
Hot Sale High Thermal Conductivity Silicone Grease for LED/CPU/VGA heat sink
Product Information |
Product Name | Hot Sale High Thermal Conductivity Silicone Grease for LED/CPU/VGA heat sink | |
Item No. | SG560-12 | Test Method |
Color | White | Visual |
Construction & Compost | Silicone-based grease | |
Filler | Ceramic powder | |
Viscosity.25°C | 1000K cps | Brookfield RVF,#7 |
Specific Gravity g/cm3 | 2.4 | |
Temperature Range °F/ °C | (-49 to 392°F), (-45 to 200°C) | |
Thermal Conductivity (W/mk) | 1.2 | ASTM D5470 |
Thermal lmpedance (°C-in2/W)@50psi | 0.10 | ASTM D5470 |
Evaporation, % | 0.20 | 200°C@24hrs |
Thermal Cycle, % | Thermal lmpedance No Degradation | 25°C/30~80°C / 30min 100 cycles |
Add Fiberglass | Can add fiberglass to be more strength for any thickness,FG as suffix | |
Introduction | The SG560-12 thermally conductive silicone based compound is a one component paste like interface material, never dry; it is designed for general applications, to conduct heat from heat generating devices to heat sink or chassis. The compound is heavily filled with blended thermally conductive metal oxide but remain non-electrically conductive property. | |
Features and Benefits | -1.2 W/m-K Thermal Conductivity -Never dries -ROHS compliant -No preheating required -Suitable for auto-dispensing and screen printing applications | |
Typical Applications Include | -High frequency microprocessors -Notebook and desktop PCs -Computer services - Power supply - Audio and video component - LED lighting |
Product Display |
Hot Sale |
" href="http://sheen.en.china.cn/productgrouplist-801575840/thermally_conductive_pad.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801575840/thermally_conductive_pad.html" target="_blank">pad > | " href="http://sheen.en.china.cn/productgrouplist-801559511/Thermally_ConductiveTape.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801559511/Thermally_ConductiveTape.html" target="_blank"> tape > | " href="http://sheen.en.china.cn/productgrouplist-801533008/Thermal_silicone_RTV.html" target="_blank">Thermal silicone RTV > | " href="http://sheen.en.china.cn/productgrouplist-801584663/Thermal_Grease.html" target="_blank">Thermal grease > |
" href="http://sheen.en.china.cn/productgrouplist-801646855/Phase_Change_Thermal_interface_Materials.html" target="_blank">Phase change thermal " href="http://sheen.en.china.cn/productgrouplist-801646855/Phase_Change_Thermal_interface_Materials.html" target="_blank"> interface materials > | " href="http://sheen.en.china.cn/productgrouplist-801559512/Thermally_Conductive_silicone_Pug.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801559512/Thermally_Conductive_silicone_Pug.html" target="_blank"> silicone pug > | " href="http://sheen.en.china.cn/productgrouplist-801646856/Thermally_conductive_insulators.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801646856/Thermally_conductive_insulators.html" target="_blank"> insulators > | " href="http://sheen.en.china.cn/productgrouplist-801586206/Thermally_conductive_graphite_sheets.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801586206/Thermally_conductive_graphite_sheets.html" target="_blank"> graphite sheets > |
" href="http://sheen.en.china.cn/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank">Thermally double " href="http://sheen.en.china.cn/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank"> component silicone > | " href="http://sheen.en.china.cn/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank"> plastics > | " href="http://sheen.en.china.cn/productgrouplist-801533811/Epoxy_Adhesive.html" target="_blank">Epoxy adhesive > | " href="http://sheen.en.china.cn/productlist.html" target="_blank">More products > |
Product Advantage |
|
|
|
|
Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid. |
Company Overview |
Certificate |
Contact |
We can make many specifications according to your request! For more information. Please contact us. | ||||||||||
|
FAQ |
1. What are your main products? We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal grease. Samples of cpu thermal grease are available, but the freights need to be paid by the buyers. 2. What about the product quality and which certificate do you have? We have UL certificate and RoHS certificate. 3. How long does it take to deliver after order? For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as possible according to actual situation and customer's requirements. 4. What about your after-sale service? We fully guarantee our product quality and will provide free technical guidance on operations. |
