Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > WQ Series Non-clog Sewage Submersible Pump
US$ 150 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
NNT
Model Number:
WQ
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
100m3/h Electric Submersible Sewage PumpUS$ 150 - 10,000MOQ: 1 Set -
Electric Submersible Dirty Water PumpUS$ 150 - 10,000MOQ: 1 Set
-
Float Switch Submersible Sewage PumpUS$ 150 - 10,000MOQ: 1 Set
-
Submersible Sewage Cutter PumpUS$ 150 - 10,000MOQ: 1 Set
-
Electric Non-clog Submersible Sewage PumpUS$ 150 - 10,000MOQ: 1 Set
Place of Origin
Hebei, China
Brand Name
NNT
Model Number
WQ
Theory
Centrifugal Pump
Structure
Single-stage Pump
Usage
Water
Power
Other, Electric, Electromotor
Standard or Nonstandard
Standard
Fuel
Diesel
Pressure
High Pressure
Application
Other, Wastewater,Sewage,etc.
Specifications
Non-clog submersible sewage pumpOutlet: 25 to 500 mm
Flow: 5 to 4000 m3/h
Head: 5 to 50 m
Power:0.75 to 250 kw
Applied with the advanced technology of ABS pump manufacturing Co. in Germany,WQ non-clogging submersible sewage pump is an advanced model among similar products in China.Combined with efforts of pump researchers and experts in our company and in China and repeated improvements,this pump has reached the advanced level of similar products at home and abroad.This pump has features of high energy-saving efficiency,non-clogging and safety etc..
After the launch of the product,it receives favourable comment and welcome from our massive users.
For example: WQ50-20-15-1.5
WQ: Non-clog submersible sewage pump
50: Outlet diameter(mm)
20: Flow(m3/h)
15: Head(m)
1.5: Motor power
| Type | Inlet | Outlet | Flow | Head | Motor Power | Speed |
| WQ / JYWQ | mm | mm | m3/h | m | kw | r/min |
| 25-8-12-0.75 | 25 | 25 | 8 | 12 | 0.75 | 2900 |
| 25-6-30-1.5 | 25 | 25 | 6 | 30 | 1.5 | 2900 |
| 25-8-22-1.5 | 25 | 25 | 8 | 22 | 1.5 | 2900 |
| 50-20-7-0.75 | 50 | 50 | 20 | 7 | 0.75 | 2900 |
| 50-10-10-0.75 | 50 | 50 | 10 | 10 | 0.75 | 2900 |
| 50-15-15-1.5 | 50 | 50 | 15 | 15 | 1.5 | 2900 |
| 50-25-10-1.5 | 50 | 50 | 25 | 10 | 1.5 | 2900 |
| 50-20-15-1.5 | 50 | 50 | 20 | 15 | 1.5 | 2900 |
| 50-27-15-2.2 | 50 | 50 | 27 | 15 | 2.2 | 2900 |
| 50-15-25-2.2 | 50 | 50 | 15 | 15 | 2.2 | 2900 |
| 50-15-30-3 | 50 | 50 | 15 | 30 | 3 | 2900 |
| 50-40-15-4 | 50 | 50 | 40 | 15 | 4 | 2900 |
| 50-24-20-4 | 50 | 50 | 24 | 20 | 4 | 2900 |
| 50-25-32-5.5 | 50 | 50 | 25 | 32 | 5.5 | 2900 |
| 50-30-30-7.5 | 50 | 50 | 30 | 30 | 7.5 | 2900 |
| 50-20-40-7.5 | 50 | 50 | 20 | 40 | 7.5 | 2900 |
| 65-42-9-2.2 | 65 | 65 | 42 | 9 | 2.2 | 2900 |
| 65-25-15-2.2 | 65 | 65 | 25 | 15 | 2.2 | 2900 |
| 65-37-13-3 | 65 | 65 | 37 | 13 | 3 | 2900 |
| 65-18-30-4 | 65 | 65 | 18 | 30 | 4 | 2900 |
| 65-25-30-4 | 65 | 65 | 25 | 30 | 4 | 2900 |
| 65-40-30-7.5 | 65 | 65 | 40 | 30 | 7.5 | 2900 |
| 65-35-50-11 | 65 | 65 | 35 | 50 | 11 | 2900 |
| 65-35-60-15 | 65 | 65 | 35 | 60 | 15 | 2900 |
| 80-40-7-2.2 | 80 | 80 | 40 | 7 | 2.2 | 2900 |
| 80-30-8-2.2 | 80 | 80 | 30 | 8 | 2.2 | 2900 |
| 80-50-10-3 | 80 | 80 | 50 | 10 | 3 | 2900 |
| 80-43-13-3 | 80 | 80 | 43 | 13 | 3 | 2900 |
| 80-60-13-4 | 80 | 80 | 60 | 13 | 4 | 2900 |
| 80-40-15-4 | 80 | 80 | 40 | 15 | 4 | 2900 |
| 80-40-25-5.5 | 80 | 80 | 40 | 25 | 5.5 | 2900 |
| 80-65-25-7.5 | 80 | 80 | 65 | 25 | 7.5 | 2900 |
| 100-70-7-3 | 100 | 100 | 70 | 7 | 3 | 2900 |
| 100-100-7-4 | 100 | 100 | 100 | 7 | 4 | 2900 |
| 100-80-10-4 | 100 | 100 | 80 | 10 | 4 | 2900 |
| 100-110-10-5.5 | 100 | 100 | 110 | 10 | 5.5 | 1450 |
| 100-65-15-5.5 | 100 | 100 | 65 | 15 | 5.5 | 1450 |
| 100-100-15-7.5 | 100 | 100 | 100 | 15 | 7.5 | 1450 |
| 100-85-20-7.5 | 100 | 100 | 85 | 20 | 7.5 | 1450 |
| 100-50-22-7.5 | 100 | 100 | 50 | 22 | 7.5 | 1450 |
| 100-100-25-11 | 100 | 100 | 100 | 25 | 11 | 1450 |
| 100-70-22-11 | 100 | 100 | 70 | 22 | 11 | 1450 |
| 100-50-35-11 | 100 | 100 | 50 | 35 | 11 | 1450 |
| 100-80-30-15 | 100 | 100 | 80 | 30 | 15 | 1450 |
| 100-87-28-15 | 100 | 100 | 87 | 28 | 15 | 1450 |
| 100-100-30-15 | 100 | 100 | 100 | 30 | 15 | 1450 |
| 100-100-35-18.5 | 100 | 100 | 100 | 35 | 18.5 | 1450 |
| 100-60-50-15 | 100 | 100 | 60 | 50 | 15 | 2900 |
| 100-100-50-30 | 100 | 100 | 100 | 50 | 30 | 2900 |
| 150-140-7-5.5 | 150 | 150 | 140 | 7 | 5.5 | 1450 |
| 150-120-10-5.5 | 150 | 150 | 120 | 10 | 5.5 | 1450 |
| 150-210-7-7.5 | 150 | 150 | 210 | 7 | 7.5 | 1450 |
| 150-145-9-7.5 | 150 | 150 | 145 | 9 | 7.5 | 1450 |
| 150-110-15-7.5 | 150 | 150 | 110 | 15 | 7.5 | 1450 |
| 150-200-10-15 | 150 | 150 | 200 | 10 | 15 | 1450 |
| 150-180-15-15 | 150 | 150 | 180 | 15 | 15 | 1450 |
| 150-140-18-15 | 150 | 150 | 140 | 18 | 15 | 1450 |
| 150-200-14-18.5 | 150 | 150 | 200 | 14 | 18.5 | 1450 |
| 150-180-20-18.5 | 150 | 150 | 180 | 20 | 18.5 | 1450 |
| 150-150-25-18.5 | 150 | 150 | 150 | 25 | 18.5 | 1450 |
| 150-200-22-22 | 150 | 150 | 200 | 22 | 22 | 1450 |
| 150-180-25-22 | 150 | 150 | 180 | 25 | 22 | 1450 |
| 150-130-30-22 | 150 | 150 | 130 | 30 | 22 | 1450 |
| 150-250-22-30 | 150 | 150 | 250 | 22 | 30 | 1450 |
| 150-180-30-30 | 150 | 150 | 180 | 30 | 30 | 1450 |
| 150-200-30-30 | 150 | 150 | 200 | 30 | 30 | 1450 |
| 150-150-35-37 | 150 | 150 | 150 | 35 | 37 | 2900 |
| 150-200-30-37 | 150 | 150 | 200 | 30 | 37 | 2900 |
| 150-160-45-45 | 150 | 150 | 160 | 45 | 45 | 2900 |
| 150-150-50-45 | 150 | 150 | 160 | 45 | 45 | 2900 |
| 200-360-6-11 | 200 | 200 | 360 | 6 | 11 | 2900 |
| 200-300-7-11 | 200 | 200 | 300 | 7 | 11 | 1450 |
| 200-400-7-15 | 200 | 200 | 400 | 7 | 15 | 1450 |
| 200-250-11-15 | 200 | 200 | 250 | 11 | 15 | 1450 |
| 200-300-10-18.5 | 200 | 200 | 300 | 10 | 18.5 | 1450 |
| 200-250-15-18.5 | 200 | 200 | 250 | 15 | 18.5 | 1450 |
| 200-400-10-22 | 200 | 200 | 400 | 10 | 22 | 1450 |
| 200-310-13-22 | 200 | 200 | 310 | 13 | 22 | 1450 |
| 200-300-15-22 | 200 | 200 | 300 | 15 | 22 | 1450 |
| 200-400-13-30 | 200 | 200 | 400 | 13 | 30 | 1450 |
| 200-360-15-30 | 200 | 200 | 360 | 15 | 30 | 1450 |
| 200-250-22-30 | 200 | 200 | 250 | 22 | 30 | 1450 |
| 200-350-25-37 | 200 | 200 | 350 | 25 | 37 | 1450 |
| 200-400-25-45 | 200 | 200 | 400 | 25 | 45 | 1450 |
| 200-380-28-45 | 200 | 200 | 380 | 28 | 45 | 1450 |
| 200-250-35-45 | 200 | 200 | 250 | 35 | 45 | 1450 |
| 200-400-30-55 | 200 | 200 | 400 | 30 | 55 | 1450 |
| 200-250-40-55 | 200 | 200 | 250 | 40 | 55 | 1450 |
| 200-350-40-75 | 200 | 200 | 350 | 40 | 75 | 1450 |
