Home > Products > Lock Cylinders > Euro Profile Dimple Flat Security Pin Cylinder Lock
Euro Profile Dimple Flat Security Pin Cylinder Lock
- 100000 Piece / Pieces per Month
- Shanghai
- T/T D/P D/A
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | Intelliware | Model Number: | 12.101 |
Product Description
Specifications
Euro Profile Dimple Flat Security Pin Cylinder Lock1.Euro Profile Dimple Security Cylinder
2.with 6 pins per side
Product: Euro Profile Dimple Flat Security Pin Cylinder Lock
Features:
1) Cylinder and Pins are made out of solid brass.
2) Cylinder is with 6 pin by single line.
3) Cylinder groove is European flat series groove.
4)The popular surface treatment are nickel plated(NP) and polished brass(PB)
5)Supplied with 5 brass nickel plated dimple flat keys.
6)Suppled with M5X50MM nickel plated steel bolt.(Longer bolt is available.)
Special Features:
1)Cylinder with double line pin is also available.
2)Key alike cylinder is available.
3)Accept individual order for key blanks.
Photo and Drawing:
Dimension:
| Art.No | Length | DC |
| 12.101.011 | 50MM | 25X25 |
| 12.101.021 | 60MM | 30X30 |
| 12.101.031 | 65MM | 30X35 |
| 12.101.041 | 70MM | 30X40 |
| 12.101.051 | 70MM | 35X35 |
| 12.101.061 | 80MM | 35X45 |
| 12.101.071 | 80MM | 40X40 |
| 12.101.081 | 85MM | 35X50 |
| 12.101.091 | 85MM | 40X45 |
| 12.101.101 | 90MM | 40X50 |
| 12.101.111 | 90MM | 45X45 |
| 12.101.121 | 100MM | 40X60 |
| 12.101.131 | 100MM | 50X50 |
| 12.101.141 | 110MM | 50X60 |
| 12.101.151 | 120MM | 60X60 |
*Art.12.101.011, is just 5 pin.
Package Details:
Inner packing: 1pc/box
Outer packing: 100pcs/carton
