rfid reader for car parking control management system
- 1000 Unit / Units per Month
- Shenzhen
- Credit Card
You May Like
-
High Quality Long Distance Rfid Car Smart Key Parking System
-
High Quality Long Distance Rfid Smart Vehicle Car Parking Sensor System
-
High Quality Long Distance Rfid Parking System
-
vanch rfid reader for underground parking lot system
-
smart automatically parking uhf rfid reader with tamperproof windshield tag
-
Long range Integrated UHF RFID Reader for government vehicle management tender
Product Details
| Type | Parking Lift | Height (mm) | 306 | |
| Width (mm) | 306 | Place of Origin | Guangdong, China | |
| Brand Name | VANCH | Model Number | VI-86F |
Product Description
rfid reader for car parking control management system
Application
logistics, access control, ETC, electronic security, manufacturing automation and etc.
Features
Reliable industry structure design, workable in varied severe environment.
Specification
Performance Index |
| |
Frequency range | 902-928MHZ/865-868MHZ(or customized) |
|
FM mode | FHSS or fixed frequency, set by the software |
|
Reader chip | Impinj R2000 indy | |
RF output | 30dBm adjustable |
|
Communication interface | TCP/IP,RS232,RS485,Wiegand26/34 |
|
Communication rate | Serial port 9600~115200bps,RJ45 10Mbps |
|
GP I/O interface | 12 pin + 4 pin |
|
Power dissipation | average<15W |
|
Application software | Provide with API SDK and VC, VB, Java application routines |
|
Tag Operation Performance |
| |
Reading distance | 5-30m equipped with 12dbi antenna(tag dependent) |
|
Air interface | EPC global UHF ISO-18000-6C(EPC G2),ISO-18000-6B |
|
Mechanical and Electrical Performance |
| |
Dimension | 445(L)*445 (W)*70(H)mm |
|
Power supply | Equipped with power convertor 220V AC input, +9V/3A DC output |
|
Weight | 2KG |
|
Humidity | 5% to 95%, non-condensing |
|
Protection grade | IEC IP65 |
|
Operation temperature | -20 ºC to +60 ºC |
|
Storage temperature | -40°C to 80°C |
|
Project case
Underground Parking lot System
Vanch Intelligent Co., LTD
Our Staff are ready for assist your RFID Project , pls feel free to contact with us.
Contact Us
- Shenzhen Vanch Intelligent Technology Co., Ltd.
- Contact nameSara Hsu Chat Now
- Phone86-755-82426775
- AddressRoom318,Building 535,Bagua 2nd Road,Futian district,Shenzhen, Shenzhen, Guangdong
