Home > Products > tablet PC, UMPC, MID > 21.5 Inch Intel H61 chipset Touchscreen HTPC All In One PC Computer

21.5 Inch Intel H61 chipset Touchscreen HTPC All In One PC Computer

FOB Price

USD $738 - $768 / Piece

50 Pieces(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port FOB Shenzhen Or HK
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	All-In-One
Screen Size	Other, 21.5inch, 21.5inch	Processor Brand	Intel
Memory Capacity	Other, 2GB, 1GB or 2GB	Hard Drive Capacity	Other, 320GB, 320GB Hard Disk or 16GB SSD
Graphics Card Type	Integrated Card	Display Type	Other, LCD, LCD Panel
Widescreen	No	Optical Drive Type	DVD-ROM
Processor Main Frequency	2.5Ghz	Brand Name	DL CAR PC
Model Number	DL215PC, DL215PC	Place of Origin	Guangdong, China

Product Description

21.5 Inch Intel H61 chipset Touchscreen HTPC All In One PC Computer

The main spec as below:

Panel specification	LCD panel:		21.5" wide new A+ grade Panel
	Working Voltage:		DC 11V-15V
	Working Temperature:		-10°C~60°C
	Screen size:		21.5 inches (16:9 diagonal)
	Resolutions:		1920 x 1080
	Brightness:		300cd/ m2
	Contrast:		1000:1
	Viewing angle		TOP/BOTTOM 160-170Deg /---LEFT/RIGHT 170-178Deg
	Response Time		5ms
PC SPEC
	Intel Core i3 power (TDP) parameter correction 73W
	chipset Intel H61 express 133.3MHz or (HM67 chip for move platform)
	SUPPORT DirectX 10,Shader Model 4.0,Pure Video HD
	Inverter Interface (19V, Light Adj, ON/OFF)
	Memory 240PIN 1. 2x 1.8V DDR3 1333MHz memory frequency up to 8GB
	Audio :Azalea Codec support 2.1/2.0 channel
	ODD Port 1x SATA II Port Onboard (7P SATA data +6P power connector)
	LAN 1. Onboard Realtek 8111C, dual 1000M LAN
	Storage Interface 1. 2*SATA 3 Gb/s , support ESATA
	Expansion Slot 2x miniPCIe Slots (onboard, not Hanging). One HF size for Wi-Fi, One Full size for 3G or CMMB or TV
	On Board Side IO Connectors USB 2.0 X1; USB 2.0/eSATA Combo x1 Audio Speaker Out Mic In x1 4 in 1 Card Reader
	Back IO USB v2.0 x4 RJ45 x1 (PCIe connected to Daughter card)
	Support 8*USB 2.0 ports (2 need cable to connect)
	Work temperature 0~60 °C
	Work humidity 10%~80% relative humidity, without freeze
	WindowsXP,win7 and Linux Ubuntu 10 (with Device Driver)
	RAM	16G RAM DDR2 DIMM x1
	WIFI/3G	inside with PCI-E (option)
	Disk driver	350GB 2.5inch mini disk
	power supply	DC19V—ATX power ,AC220V – DC19V
Unique selling points	21.5" HDTV, 1080 p with matching swivel stand
	4wire resistive reliability touch panel
	1 HDMI inputs, plus DVI and VGA inputs
	connect to play music files or pictures
	Intel H61 express chipset
	new45nm nvidia ION2
	aluminum frame struct ,thin and narrow border design
Accessories	1pcs tablet pc
	1pcs Stand Shelf
	1pcs VGA Cable/ DVI cabel/ HDMI cabel
	1pcs Instruction Manual
	1pcs AC/DC Power
	Some Screw for Fixing the Shelf.
