Transducer

FOB Price

USD $1 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port XI'AN
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Shaanxi, China

Brand Name:

Model Number:

BP93420-IQ

Product Description

Specifications

Wide range, Protection :IP65;
Various output signal
CE certification
Marking :ExiaIICT6

Description

BP93420IQ pressure transmitter uses HT series piezoresistive silicon oil-filled sensor as the signal measuring element. Signal processing circuit located in the stainless steel housing, can convert sensor signal into standard output signal. All the products through components and semi-finished products test, finished products burn-in screening, are with stable and reliable performance. This model can effectively avoid the easy crystallization medium to block up pressure port..

Feature

²Wide range, Protection :IP65;

²Various output signal

²CE certification

²Marking :ExiaIICT6

Application

²Pressure measurement of liquid or gas compatible with 316LSS

²Applied to medical, ;biological products, food hygiene industry and so on

²Pressure measurement in papermaking industry, sewage level and beverage.

Specification

Measurement Range	0~35KPa...~100MPa
Proof pressure	≤1.5X rated pressure
Pressure type	Gauge, absolute , or sealed pressure
Accuracy	±0.25%(typical) ±0.5%(Max.)
Long-term stability	±0.1%F.S/year(typical) ±0.2%F.S/year(Max.)
Temperature Error- Zero	±0.03%F.S/°C(≤100KPa) ±0.02%F.S/°C(>100KPa)
Temperature Error -Span	±0.03%F.S/°C(≤100KPa) ±0.02%F.S/°C(>100KPa)
Operating Temperature Range	-20°C~80°C
Storage Temperature Range	-40°C~120°C
Power supply	15~28VDC(intrinsic safe type supplied by safety barrier)
Output signal	4~20mA; 0~10/20mA; 0/1~5/10VDC
Pressure port	Clamp type flange interface
Housing material	1Cr18Ni9Ti stainless steel
Diaphragm material	316L
O-ring	Fluororubber
Cable	polyethylene
Insulation resistance	100MΩ,100VDC
Housing protection class	IP65
