Digital IGBT heavy duty ac dc 3 in 1 inverter argon gas tig SMAW pulse aluminum industrial welder TIG-315AC/DC

FOB Price

USD $750 - $850 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Zhejiang, China
Brand Name	KEYUE	Model Number	TIG-315AC/DC
Arc Current	315A	Pulse Frequency	0.2-20Hz
Pilot Arc Current	315A	Rated Duty Cycle	60%
Motor Type	DC Motor	Dimensions	740400630
Usage	MMA,TIG, Pulse TIG, TIG-AC/DC	Voltage	three phase 380V
Power(W)	9KVA	Certification	CE,CCC,ROHS
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

INVERTER TIG-AC/DC SQUARE WAVE WELDING MACHINE

Advanced IGBT inverter technology delivers superior TIG performance
Multifunction:MMA, TIG, TIG-AC/DC, Pulse TIG
AC square wave is especially suitable for welding aluminum and its alloy
DC square wave is suitable for welding stainless steel, alloy steel, carbon steel, copper and other non-ferrous metals
2T/4T function selectable on the front panel
Foot pedal to control current remotely is optional
Digital instrument for the welding current
Accurate adjustment can achieve great penetration, aesthetic apperance of weld seam and low consumption electrode

Technical Data

Model	TIG-315AC/DC
Type	IGBT
Rated input voltage	three phase 380V±10% / 50Hz
Rated input capacity	13KVA
Rated input current	20A
Constant current	5-315A
Peak current	5-315A
Welding current for MMA	20-315A
Drive current for MMA	10-200A
Base current	5-315A
Start arc current	20-160A
Crater arc current	5-315A
Duty ratio	1-100%
AC bias ratio	-50%~+30%
Pulse frequency	0.2-20Hz
AC frequency	20-200Hz
Pre-flow time	0.1-15s
Gas delay time	0.1-15s
Current slow up time	0.1-10s
Current decay time	0.1-15s
Cleaning ratio	-40%~+40%
Rated duty cycle	60%
No-load voltage	74V
Efficiency	79%
Power factor	0.95
Net weight	47.2KG
Insulation of main transformer	H
Insulation of output reactor	B

High quality components

Accessories
