Ruizhou Auto-feeding Apparel Pattern Cutting System

Specifications

Ruizhou digital paper sample cutting machine is efficient in cutting paper sample, carton samples and other paper materials.

 Ruizhou Auto-feeding Apparel Pattern Cutting System



Ruizhou Auto-feeding Apparel Pattern Cutting System is designed specifically for footwear and garment industry. Utilizing vacuum-suction technology, Ruizhou Auto-feeding Apparel Pattern Cutting System creates accurate footwear and garment patterns on standard pattern paper, cardboard, or PVC sheet.



WHAT ARE THE BENEFITS?



1. Easy to use

·       Ruizhou Auto-feeding Apparel Pattern Cutting System are easy to install, to set-up and to use. Ruizhou Auto-feeding Apparel Pattern Cutting System is equipped with Ruizhou RECAD software, which saves you the trouble of adjusting the knife at times, to draw/cut accurately.



2. To improve quality while saving time and money: a task impossible or a task effortless?

It seems a task impossible. But with our cutting machine, it is just a task effortless.

·       Reduces the cost you spend on cutting paper patterns and making brass bound pattern boards.

·       Greatly cut the time taken to hand cut sample and graded paper patterns.

·       Consistent accuracy, utilizing the Ruizhou RECAD software, any patterns can be modified or re-cut within seconds.

·       Shorten your lead times, short sample development and production grants you “fast response” to customers and market.



3. Flexible

·      With Ruizhou RECAD software, the cutting/plotting tasks are carried out in the background, while you develop more 2D patterns.



WHAT ARE THE FEATURES?



1. Tool Head

·       A dual function tool head containing a trailing knife and pen, is ideal for cutting pattern paper and up to 2mm cardboard.



2. Compatibility

·       Connectible to all CAD software, widely used for design and manufacture of footwear, apparel, suitcases, bags, lamps and automobile leather parts.



 TECHNOLOGICAL SPECIFICATION



Available Model	RZCAM-1209AF	RZCAM-1509AF	RZCAM-1512AF	RZCAM-1812AF
Working Area	1200*920mm	1500*920mm	1500*1200mm	1800*1200mm
Cutting Materials	Paper, Cardboard, Plastic board, Rubber board, Fiber sheet (up to 2mm)
Working Performance	Cutting Speed: 800-1300mm/s
	Cutting Thickness: 0.5-2mm
	Mechanical Resolution: 0.07mm
Blade and Pen Type	Blade: wolfram steel;
	Pens: water-based fibertip, oil-based ballpoint, disposable ink pen.
Mat. hold-down method	Vacuum Suction
Software Resolution	0.025mm  0.01mm  0.1mm  optional
Interface	Standard parallel port or serial port
Command System	HP-GL and GP-GL compatible mode
Power Consumption	Machine: 200W AC 220±10%,50HZ
	Vacuum Pump: 1100W AC 220±10%,50HZ
Feeding Mode	Auto-feeding
