EA-F24 electric therapy occupational equipment

Specifications

therapy occupational equipment
1.3 channels,6 modes
2.electric therapy,ease pain
3.foot care with massage slipper
4.factory

EA-F24 electric therapy occupational equipment

3 output channels,2 for electric therapy,1 for far-infrared heating therapy

occupational technology,over 20 years experiences

muscle relax,pain relief,eliminate fatigue

improve blood circulation,help to cure some diseases

A.Features:

1) High-tech design of digital circuit,stable performance

2) LCD screen, easy to operate: 6-time setting,6 kinds of treatment programs and 6 kinds of massage programs

3) Stimulate Chinese acupuncture:feel comfortable by pasting at the right acupoint with electrode pads

4) Rotary button: more convenient and accurate by using rotary buttons

5) Far-infrared heating therapy:easily absorbed by human body,improve blood circulation,can be used with medical liquid

6) Large output and adjustable: adjustable output spectrunn and large output power,have a real feeling of massage

7) Physical therapy:No any side-effects to ease pain by physical therapy

B.Special Functions:

1) Cure or prevent some disease:effective for cervical spondylosis,scapulohumeral periarthritis,lumbar muscle strain,rheumatoid arthritis,hyperosteogeny,neuralgia, etc

2) Improve blood circulation and enhance metabolism

3)Muscle relax: Swelling, inflammatory pain, relieve muscle tension

4) Far-Infrared thermotherapy:It is applicable for adjuvant treatment amd health care and physical therapy for lumbocrural pain and general upset stomache etc

5) It is proved by the authority that JER Meridian-Collateral-Through Device provides effective health protection for various diseases of different systems within human body, like nevral system,respiratory system, endocrine systm,digestive system,uragenital system,etc

C.Specification:

No.	Model Specification	Models EA-F24
1	Power supply and voltage	a.c.220V±22V,50Hz±1Hz net power supply direct supply
2	Power	≤28VA
3	Frequency range	0.5Hz-1000Hz
4	Pulse duration	0.07ms-1.2ms
5	Single electrode max output energy	<300mj
6	Single electrode output effective voltage	<25V
7	Output pulse feature	B mode linear continually adjustable V out min<V out max ×2%(V)
8	Far-Infrared thermotherapeutic temperature	Within 35-60 centidegree
9	Time setting	Six grades for 5,10,15,20,25,30min
10	Dimensions(main unit)	178mm×158mm×70mm
11	Weight	1.5kg
12	Electrodepad size	82mm×43mm(40mm×40mm,40mm×80mm)

D.Components:

1) 1×main unit

2) 1×far-infrared thermotherapeutic belt(set)

3) 1×medicine introducing electrodes (pair)

4) 2×electrode cable

5) 1×sticky piece(pair)

6) 1×electrode pad(pair)

7) 1×usage Instruction Index

8) 1×low frequency pulse feet acupuncture points therapeutic shoes

E.Sample:

The sample need to be charged,but once the order quantity is up to 200pcs,it will be refunded.

F.Certifications:

Sample and trial order are warm welcomed.

We are confident that our machine must stand your trial.

Choose us,choose the reliable supplier.
