Catering Truck (Camel C600)

Specifications

Catering Truck (Camel C600)

Camel catering truck features finite element analysis optimized scissors lift that minimizes stress concentrations and provides low weight with long service life. Multiple interlocks mechanism and emergency stop systems prevent the potential damage to aircraft and personnel even the vehicle is malfunctioned at the worst scenario. Quick, easy to read and simple to operate, the ergonomically-designed controls and gauges on the catering truck allow the operator to concentrate on production. CCTV with surveillance cameras mounted on the platform and van body allows the operator to monitor and log all activities taking place on real time basis. Optional fleet management system offers integrated inter-vehicles communication and data transmission, and server-client communication between vehicles and central control station.

Operating Performance (may slightly varies upon chassis applied)

Front loading     2,850m to 6,000m

Payload     4,000kg

Dimensions

Van body (exterior)   7020mm(L)×2500mm(W) ×2500mm(H), insulated, non-skid aluminum floor

Platform     1650mm(L)×2300mm(W), anti-skid aluminum floor

Shunting platform   770mm(L)×1000mm(W), hydraulically or electrically controlled

Extension length (travelable)    650mm, hydraulically or electrically controlled, with extendable handrail

Weight (may slightly varies upon chassis applied)

Gross weight    16,000kg Gross vehicle weight  12,000kg

Platform capacity   1000kg

Driving speed

 max. 30km/hr

Electric system   24V DC

Refrigeration Unit

Thermoking or Carrier, with diesel engine and external power socket

Optional Equipment

Tailgate Canopy, electro-hydraulically controlled

Fleet manager

360°vision system

Extreme Weather Packages
