New Arrival Factory Wholesale Best Quality Valve Grinder
- 3000 Set / Sets per Month
- Changsha
- T/T Credit Card
- China Factory Newest Daytona Anima 190cc 4 Valve Engine
- 2 Way 15mm/20mm/25mm Electric Spring Return Self Closing Ball Valve
- 2016 Factory Price Self Closing Spring Return Fail Safe Ball Valve
- 2015 High Quality Factory Selling Cheap 4 Inch Electrical Water Valve
- Professional Factory Top Quality Spring Loaded Check Valve
- 2015 Hot Sales Competitive Price Top Quality Expansion Valve
Product Details
Standard or Nonstandard: | Standard | Structure: | Ball | Pressure: | Medium Pressure |
Power: | Other, motorized | Material: | Brass | Temperature of Media: | Medium Temperature |
Media: | Other, water, with 50% glycol | Port Size: | 1/2'', 3/4'' and 1'' | Place of Origin: | Zhejiang, China |
Model Number: | SW-B152 | Brand Name: | WINNER | Application: | General |
Product Description
New Arrival Factory Wholesale Best Quality Valve Grinder
Product Name | Valve Grinder |
Valve body: | Forged brass |
Valve seat: | Brass |
Valve stem: | Chrome-plated brass |
Actuator shell: | Aluminum |
Actuator bottom case: | Stainless steel |
Working voltage: | 24VAC, 110/120VAC, 230VAC; 50/60Hz |
On/off time: | 13-18s |
Spring return time: | 4-5s |
Motor power: | 6.5W, 7 VA |
OEM & ODM | Acceptable |
Thread Type | BSP NPT |
Model No. | Size | Description | Kv(Cv) | Closing pressure | Weight (g) |
SW-B152 | 15MM (1/2’’) | 2 way valve | 2.2(2.5) | 0.18MPa (25PSI) | 700 |
SW-B202 | 20MM (3/4’’) | 3.0(3.5) | 0.16MPa (23PSI) | 850 | |
SW-B252 | 25MM (1’’) | 6.9(8.0) | 0.14MPa (20PSI) | 1000 | |
SW-B153 | 15MM (1/2’’) | 3 way valve | 2.6(3.0) | 0.18MPa (25PSI) | 750 |
SW-B203 | 20MM (3/4’’) | 3.4(4.0) | 0.16MPa (23PSI) | 900 | |
SW-B253 | 25MM (1’’) | 6.5(7.5) | 0.14MPa (20PSI) | 1050 | |
SW-B152H | 15MM (1/2’’) | High C.P 2 way valve | 1.7(2.0) | 0.45MPa (65PSI) | 700 |
SW-B202H | 20MM (3/4’’) | 2.2(2.5) | 0.35MPa (50PSI) | 850 | |
SW-B252H | 25MM (1’’) | 3.0(3.5) | 0.20MPa (30PSI) | 1000 | |
SW-B153H | 15MM (1/2’’) | High C.P 3 way valve | 1.7(2.0) | 0.45MPa (65PSI) | 750 |
SW-B203H | 20MM (3/4’’) | 2.6(3.0) | 0.35MPa (50PSI) | 900 | |
SW-B253H | 25MM (1’’) | 3.4(4.0) | 0.20MPa (30PSI) | 1050 |
More Products For You To Choose
Certificate of Products
Production line of Product
Exhibition and Customer
Our Services
Before service:
- 1.We have full stock and can deliver within short time.
- 2.OEM and ODM order are accepted, Any kind of logo printing or design are available.
- 3.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
- 4.All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
After you choose:
- 1. We will count cheapest shipping cost and make invoice to you at once.
- 2. Check quality again, then send out to you at 1-2 working day after your payment
- 3. Email you the tracking no., and help to chase the parcels until it arrive you.
After-sale service:
- 1.We are very glad that customers give us some suggestion for price and products.
- 2.If you have any question,please contact us freely by E-mail or Telephone.
Our Company View
FAQ
Q. what is your payment term?
- A: T/T 30% down payment, balance to be paid before shipment. or L/C.
Q: How do you control the products’ quality?
- A: 1. High quality mold.
- 2. Raw materials control.
- 3. Production process quality control.
- 4. Final inspection.
- 5. Water testing (no leaking).
Q:Could I use my own logo or design on goods?
- A:Yes.Customized logo and design on production are available.
Q: Can I get samples from your factory?
- A: Yes, Samples can be provided.
Q: If products have some quality problem, how would you deal with?
- A: We will responsible for all the quality problems.
