Dibond Alucobond Megabond exterior cladding

Specifications

Dibond Alucobond Megabond exterior cladding
1.Impact resistant
2.Good plasticity
3.ISO9001:2008
4. Quality guaranty

Dibond Alucobond Megabond exterior cladding







1. Standard: according to GB/T 17748-2008 standard

2. Basic Material of  Dibond Alucobond Megabond exterior cladding

1)   front side: aluminum alloy sheet coated with fluoro-carbon resin(PVDF) or polyester

       resin roasting painting
2)   Core material: nontoxic polyethylene, PE, FR, LDPE
3)   Back side: aluminum alloy sheet coated with polyester resin painting(PE)



3. Dimensions of   Dibond Alucobond Megabond exterior cladding

a) Surface coating thickness: 30um
b) Aluminum alloy sheet thickness: 0.1mm, 0.12mm, 0.15mm, 0.18mm, 0.2mm, 0.3mm, 0.4mm, 0.45mm, 0.5mm
c) Thickness:2mm, 3mm, 4mm, 5mm, 6mm
d) Width: 1220mm, 1250mm, 1500mm, 1570mm
e) Length: 2440mm to 6000mmm
f ) Weight: 5.5kg/sqm based on 4mm thickness
g) Standard size: 1220 x 2440mm
f)Normal color:60 colors for Normal aluminum composite panel 7 colors for granite grain panel

Non-standard sizes and special colors are available, according to customers' requests



4. Characters of  Dibond Alucobond Megabond exterior cladding

a) Super peeling strength

b) Excellent surface flatness and smoothness

c) Superior weather, corrosion, pollutant resistance

d) Even coating, various colors

e) Fireproof, excellent heat and sound insulation

f) Superior impact resistance

g) Lightweight and easy to process

h) Easy to maintain, self-clean



5. Application scope of   Dibond Alucobond Megabond exterior cladding

a) Building exterior curtain walls

b) Decoration and renovation additions for old buildings

c) Decoration of interior walls, ceilings, bathrooms, kitchens and balconies

d) Shop door decorations

e) Advertisement board display platforms and signboards

f) Wallboards and ceilings for tunnels

g) Industrial materials, materials for vehicles and boats





6. Test reports ------- panel for indoor







Test Result -------panel for outdoor





7.  Factory Scope
