Machine to produce disposable paper cup / automatic PE coated paper cups making machine

Specifications

Machine to produce paper cup
cups machine to make disposable PE coated paper cup making machine for tea,coffee cups
customized

Machine to produce disposable paper cup / automatic PE coated paper cups making machine



About our company

Established in 2004, Zhengzhou Allance Trading Co., Ltd. is a professional supplier and exporter, which is concerned with the design, development and production of paper package processing equipment. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.

Hot sale models for automatic machine to produce paper cup

Model	ALC6-ZB09	ALC6-ZB12
Item	automatic machine to produce paper cup
Speed	45~55 pcs/min	50~60 pcs/min
Voltage	220V,single phase,50Hz (customized)
Power	5.0 kw	5.0 kw
Plate material	Single PE paper,150-350g/m2	Single PE paper,150-350g/m2
Cup size	2-9 oz	1.5~12 oz
Diameter of cup top	35~82 mm	38~94 mm
Diameter of cup bottom	30~52.8 mm	30~75 mm
Height of cup	30~92 mm	30~111 mm
Dimension	2200*1050*1650 mm	2800*1400*1700 mm
Weight	1200kg	1500kg

Allance automatic machine to produce paper cup is the automatic machine with multi-running positions. It produces single PE cups through the procedure of automatic paper feeding,bottom knurling,curling and cup stack. This kind of cup can be used for tea,coffee,milk,ice-cream etc.

Hot sale models for automatic paper bowls forming machine

Model	ALC6-ZWJ-H90A	ALC6-ZWJ-H118A
Item	Paper bowl forming machine
Speed	35~45 pcs/min	35~45 pcs/min
Voltage	220V,single phase,50Hz (customized)
Power	10 kw	10 kw
Plate material	Single PE paper,150-350g/m2 (both single and double PE paper)
Cup size	8~30 oz	8~35 oz
bowl bottom diameter	Max 105mm	Max 115mm
bowl height diameter	Max 90mm	Max 118mm
Weight	2200kgs	2500kgs
Dimension	2800*1400*1700 mm	2900*1400*1750 mm

Allance paper bowl machine is an equipment both for single coated and double coated paper bowl. Compared to the original

ZWJ-H90 paper bowl shaper,this machine fit ultrasonic welding function to make the bowls much better and beautiful.It has the function of auto paper feeding,preheating,sealing,oil injection,bottom cutting,heating ,knurling,curling,water line mark,stack etc. It can alarm via sensor checking,counting itself.ZWJ-H90A is good machine for making soup bowls and noodles bowls etc.
