6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders

6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-1
6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-2
6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-3
6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-4
6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-5
6-14m Double Column Aluminum Alloy Lift Table /mobile Lift /aluminum Alloy Ladders photo-6
US$ 3,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
jinchuan
Model Number:
SJYL0.2-10
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin China
Brand Name jinchuan
Model Number SJYL0.2-10
Lift Mechanism Lift Chain
Lift Drive / Actuation Hydraulic
Power 1.1KW
Rated Loading Capacity 100KG
Min. Lifting Height 2300MM
Max. Lifting Height 10M
Table Size 550MM*550MM
Overall Dimensions 1500*870*2300
Weight 480KG
Certification CE
Warranty ONE YEAR
After-sales Service Provided Engineers available to service machinery overseas
   Double Mast Aluminum Alloy Lift Platform

Product Description



Aluminum lift adopts high-strength quality aluminum alloy material, with small size, light weight, flexible operation, easy to implement. Smooth, safe and reliable. Widely used in factories, hotels, restaurants, railway stations, theaters, galleries and other places.



                                                                Aluminum alloy lift platform

Model

Lifting weight

(KG)

Table size

(mm*mm)

Lifting height

(m)

Overall dimension(mm³)

Power

(kw)

Single mast

SJYL0.1-6

100.00

550*550

6.00

1260*800*1980

1.1

SJYL0.1-8

100.00

550*550

8.00

1400*850*1980

1.1

SJYL0.1-10

100.00

550*550

10.00

1500*870*2300

1.1

Double mast

SJYL0.2-6

200.00

1300*600

6.00

2350*850*1980

1.5

SJYL0.2-8

200.00

1400*600

8.00

1450*850*1980

1.5

SJYL0.2-10

200.00

1450*600

10.00

1550*870*1980

1.5

SJYL0.2-12

200.00

1550*600

12.00

1800*900*1980

1.5

SJYL0.2-14

200.00

1550*600

14.00

1850*900*2300

1.5











6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders

6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders





Detail Features



1. High-strength aluminum alloy, reduce deflection and swing when it lifts.
6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders
2. Lift the DC power supply, can be configured according to customer requirements;
6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders
3. Using solid state relays. No contact, no spark, vibration;

6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders
4. Small size, suitable for small space work, mobile and flexible.

6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders



Packaging & Shipping

6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders



Company Information

 Jinan Jinchuan hydraulic machinery co., LTD is a collection research and development, production, sales in the integration of local industry company, for decades of production experience, has its own sales team and after-sales service team. Jinchuan since was established, taking the tenet of "honesty, science and technology innovation" and the concept of "quality first, users first", adhere to go today! Jinchuan will always be with full mental state to meet your

Our Services


1. All the machines will be full tested before shipment.

2. The total machine guarantee for 12 months.

3. 24 hours technical support-email, telephone or video online.

4. User-friendly English manual for machine using and maintainning.6-14m double column aluminum alloy lift table /mobile lift /aluminum alloy ladders
