Product Details
| Place of Origin | Shandong, China | Brand Name | Jin-chuan | |
| Model Number | DCQY-12 | Lift Mechanism | Other, mobile ramps | |
| Lift Drive / Actuation | Hand | Power | manual | |
| Rated Loading Capacity | 12T | Min. Lifting Height | 0.9M | |
| Max. Lifting Height | 1.7M | Table Size | 10.5*1.9M | |
| Overall Dimensions | 10.5*2M | Weight | 2800KG | |
| Certification | CE ISO9001 | Warranty | one year |
Product Description
Product Description
mobile dock ramp:
1. It is used on occasion where there is no dock or loading&unloading location is not fixed or loading&unloading place is too small.
2. The operation :power driven&manual pump dual. You also can choose only one method and the price is much different.
3. The tyres can be raised to lift-off during useage through manual pump and can be let down when its needed to move.
4.Its moveable by both manpower or forklift.
5. Safety facility: two safety struts are braced up during operation and also hook chains to connect with trailer bed
6. Technical drawing and schematic is avaiable any time. Pls kindly contact us to get it.
7. We use grill steel board instead of common steel plate, which is very sturdy.
8. Total operation times for the manual pump:50 times
9. There are brackets for connecting with forklift at the end.
10. Electrial pump volume:3.2ml
1. It is used on occasion where there is no dock or loading&unloading location is not fixed or loading&unloading place is too small.
2. The operation :power driven&manual pump dual. You also can choose only one method and the price is much different.
3. The tyres can be raised to lift-off during useage through manual pump and can be let down when its needed to move.
4.Its moveable by both manpower or forklift.
5. Safety facility: two safety struts are braced up during operation and also hook chains to connect with trailer bed
6. Technical drawing and schematic is avaiable any time. Pls kindly contact us to get it.
7. We use grill steel board instead of common steel plate, which is very sturdy.
8. Total operation times for the manual pump:50 times
9. There are brackets for connecting with forklift at the end.
10. Electrial pump volume:3.2ml
Business integrity, quality first is our purpose, we will be the most favorable price, give you the most reliable products, best service! Customer satisfaction is our greatest pursuit!
Feature
1.the highest elevation:≤130
2.lifting range:0.9~1.7m
3.main body use girder rectangular tube
pin shaft:45# surface treatment had been done
5.hydraulic power supply:hand pump
6.platform covered 4mm steel plate,on steel plate is covered 8mm diamond mash
7.guardrail :use 50mm*50mm square tube
8. system pressure: ≤16Mpa
9. hydraulic oil tube: 1-φ16-1
10.tyre: solid tyre 600-9*2
