Jinchuan Brand hydraulic vehicle-mounted aluminum alloy lifter
- 50 Set / Sets per Month
- Qing dao
- T/T D/P D/A
Product Details
| Place of Origin: | Shandong, China | Brand Name: | Jin-chuan | Model Number: | SJYL |
| Lift Mechanism: | Lift Chain | Lift Drive / Actuation: | Hydraulic | Power: | 1.1KW |
| Rated Loading Capacity: | 200KG | Min. Lifting Height: | 6M | Max. Lifting Height: | 18M |
| Table Size: | 1450*600MM | Overall Dimensions: | 1600*850*1980MM | Weight: | 480KG |
Product Description
telescopic aluminum alloy lift table
1. This series of products subject structure using high-strength aluminum alloy material.
2. The equipment takes up small spaces, light-weight, mobile flexible, looks beautiful.
3.The power source is electric, manual, battery or diesel control,
4.and you can also install remote control device according to your needs.
5.Mesa telescopic aluminum alloy lift platform
SJYL[II] Double-pole Specifications
Model | Working height (m) | Improve quality (kg) | Platform height (m) | Maximum Dimension (L * W * H mm)
| Auxiliary power (kw) | Machine weight (kg) |
SJYL[II]-8 | 8 | 300 | 6.2 | 1600*800*2050 | 1.5 | 600 |
SJYL[II]-10 | 10 | 300 | 8.2 | 1600*800*2150 | 1.5 | 640 |
SJYL[II]-12 | 12 | 200 | 10.2 | 1600*800*2350 | 1.5 | 650 |
SJYL[II]-13 | 13 | 200 | 11.2 | 1600*800*2500 | 1.5 | 700 |
SJYL[II]-14 | 14 | 200 | 12.2 | 2000*1000*2750 | 1.5 | 760 |
SJYL[II]-16 | 16 | 200 | 14.2 | 2000*1000*2750 | 1.5 | 860 |
SJYL[II]-18 | 18 | 200 | 16.2 | 2000*1000*3100 | 1.5 | 950 |
Service
We also supply spare parts free and supply technical supporting all the time
