CT3000 Evenness Tester textile spinning testing equipment yarn evenness tester

      CT3000 Evenness test analyzer is a light, machine, electricity, gas and other technology,which integrates automatic precision textile testing instruments.

1,The whole machine indicators

     Testing time: freely set between 10s and 20m, take 10s as interval

     hauling speed: 25m/min,50m/min,100m/min,200m/min,400m/min,800m/min
     Batch test index: ≤20

     statistic index:mean,max,min,cvb,Q95
     input power:voltage AC220V±10%,frequency 50Hz/60Hz,power consumption ≤350W

2, Capacitance test index

     Capacitive measuring slots:four
     Testing range:1tex~12ktex
     Coefficient of Variation:CV% or U% value testing range: 0.01%~99.99%
     Faults value:thin places   -30%,  -40%,  -50%,   -60%
                         thick places  +35%,  +50%,  +70%,  +100%
                         neps       +140%,  +200%, +280%,  +400%
     The spectrum analysis range: ordinary spectrogram measurable wave-length range 1cm~2937m
     spectrum channels 170  ,fine spectrogram measurable wave-length range 1cm~2937m spectrum channels 340
     Aberrance-the length of the curve cutting length range:1cm~1472m
     linear density frequency distribution graph:two linear density frequency distribution graphs,
     one is within the range of -100%~+100%, one is beyond the range of +100%
     drift rate-Threshold figure:reference length is given1cm,10cm,20cm,50cm,1m,the threshold is 0 ~ 50% of the positive and negative deviation rate curve

3,Photoelectric  test index

      Diameter D test range:≤3mm

     Coefficient of VariationCVD%testing range:0.01%~99.99%

     Faults value:thin placesD   2mm~16mm,-60%~-30%

     thick placesD   2mm~16mm,+35%~+100%

4,Hairiness  testing  indicators

     Testing range:1tex~160ktex

    Hairiness richness and change:H,SH
    The spectrum analysis range:1cm~1472m(170 channels)
    Aberrance-the length of the curve cutting length range:1cm~1472m

    drift rate-threshold figure:reference length is given1cm,10cm,20cm,50cm,1m,
    the threshold is 0 ~ 50% of the positive and negative deviation rate curve.

                                                                                                 FAQ

1,The product application scope:
The instrument is suitable for cotton, wool, silk, linen, chemical fiber short fiber pure yarn and blended yarn.

2,Test range:
It is used to test yarn trunk lines of the uneven density,the size of the diameter and Change,feather surface richness,etc.

3,Installation of New instrument:
About the installation of new instrument, We will arrange specialized technical personnel to help you to install, And we will from time to time at any time to each country to visit.

4,Transportation:
Transportation will be launched about 10 days after receiving the payment of the instrument.

5,After-sale Service:
No maintenance cost during ONE year warranty.And we guarantee the southeast

Asia and the central Asia company once a year China,we can provide a booster or a buck converter for the foreign buyers.

5.Others

In order to ensure that buyers can using the facilities and simple maintenance,Chang-ling txtile company will provide the place and the trainning resources for free for foreign buyers communicate and study in Changling.
