Home > Products > Industrial fabrics > Fiberglass Biaxial Fabric
Fiberglass Biaxial Fabric
USD $2.1 - $3.5
/ Kilogram
1000 Kilograms(Min.Order)
- 10000 Kilogram / Kilograms per Month
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Ding | |
| Model Number | EB300(0/90),EU400(45/-45),ETW750(45/-45/90) | Application | Filter Cloth | |
| Weight | 200g/m2~1200g/m2 | Width | 127cm | |
| Yarn Type | E-Glass | Alkali Content | Alkali Free |
Product Description
Specifications
Biaxial fabric,triaxial fabric, multiaxial fabric are all our standard configurations.It consists of two or more layers roving fiberglass at different orientations(0°, 90°, 45° ,-45°) which are stitched together by fine polymer yarn. Stanrdard configurations include biaxial ( 0°, 90°),( 45° ,-45° ),triaxial (0°, 45° ,-45°) or ( 90°, 45° ,-45°), and multiaxial( 0°, 90°, 45° ,-45° )
pecification:
FABRIC KIND | STYLE | MASS | MASS | ROLL LENGTH | WIDTH (cm) | WEIGHT | RESIN COMPATIBILITY |
g/m² | OZ/YD² | (m) | kg/ROLL | ||||
| Biaxial Fabric | EB600(0/90) | 600 | 17.7 | 65 | 127 | 50 | UP or Epoxy resin |
| EB800(0/90) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| EB1200(0/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| EU400(45/-45) | 400 | 11.8 | 98 | 127 | 50 | UP or Epoxy resin | |
| EU600(45/-45) | 600 | 17.7 | 66 | 127 | 50 | UP or Epoxy resin | |
| EU800(45/-45) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| Triaxial Fabric | ETW750(45/-45/90) | 750 | 22.1 | 52 | 127 | 50 | UP or Epoxy resin |
| ETW1200(45/-45/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| ETL800(0/45/-45) | 800 | 23.6 | 50 | 127 | 50 | UP or Epoxy resin | |
| ETL1200(0/45/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| Multiaxial Fabric | EMU900(0/45/90/-45) | 900 | 26.5 | 44 | 127 | 50 | UP or Epoxy resin |
| EMU1200(0/45/90/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin |
Note:
Normally the width is 100-127cm,it can be cut to any width according to the customer's requirements. We can also combine the chopped strand mat.
Specification:
FABRIC KIND | STYLE | MASS | MASS | ROLL LENGTH | WIDTH (cm) | WEIGHT | RESIN COMPATIBILITY |
g/m² | OZ/YD² | (m) | kg/ROLL | ||||
| Biaxial Fabric | EB600(0/90) | 600 | 17.7 | 65 | 127 | 50 | UP or Epoxy resin |
| EB800(0/90) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| EB1200(0/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| EU400(45/-45) | 400 | 11.8 | 98 | 127 | 50 | UP or Epoxy resin | |
| EU600(45/-45) | 600 | 17.7 | 66 | 127 | 50 | UP or Epoxy resin | |
| EU800(45/-45) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| Triaxial Fabric | ETW750(45/-45/90) | 750 | 22.1 | 52 | 127 | 50 | UP or Epoxy resin |
| ETW1200(45/-45/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| ETL800(0/45/-45) | 800 | 23.6 | 50 | 127 | 50 | UP or Epoxy resin | |
| ETL1200(0/45/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| Multiaxial Fabric | EMU900(0/45/90/-45) | 900 | 26.5 | 44 | 127 | 50 | UP or Epoxy resin |
| EMU1200(0/45/90/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin |
Note:
Normally the width is 100-127cm,it can be cut to any width according to the customer's requirements. We can also combine the chopped strand mat.
Specification:
FABRIC KIND | STYLE | MASS | MASS | ROLL LENGTH | WIDTH (cm) | WEIGHT | RESIN COMPATIBILITY |
g/m² | OZ/YD² | (m) | kg/ROLL | ||||
| Biaxial Fabric | EB600(0/90) | 600 | 17.7 | 65 | 127 | 50 | UP or Epoxy resin |
| EB800(0/90) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| EB1200(0/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| EU400(45/-45) | 400 | 11.8 | 98 | 127 | 50 | UP or Epoxy resin | |
| EU600(45/-45) | 600 | 17.7 | 66 | 127 | 50 | UP or Epoxy resin | |
| EU800(45/-45) | 800 | 23.6 | 49 | 127 | 50 | UP or Epoxy resin | |
| Triaxial Fabric | ETW750(45/-45/90) | 750 | 22.1 | 52 | 127 | 50 | UP or Epoxy resin |
| ETW1200(45/-45/90) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| ETL800(0/45/-45) | 800 | 23.6 | 50 | 127 | 50 | UP or Epoxy resin | |
| ETL1200(0/45/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin | |
| Multiaxial Fabric | EMU900(0/45/90/-45) | 900 | 26.5 | 44 | 127 | 50 | UP or Epoxy resin |
| EMU1200(0/45/90/-45) | 1200 | 35.4 | 33 | 127 | 50 | UP or Epoxy resin |
Note:
Normally the width is 100-127cm,it can be cut to any width according to the customer's requirements. We can also combine the chopped strand mat.
