DENTAL OPERATING MICROSCOPE - Surgical Microscope - Operating Microscope - ISO & CE Certified

Specifications

DENTAL OPERATION MICROSCOPE: 10x eyepiece & F=200mm objective lens

DENTAL OPERATING MICROSCOPE



SPECIFICATIONS:-

Head                            : Indian Zoom Optical System

Zoom Ratio                  : 6:1

Binocular Tubes          : 45deg. Inclined

Magnification               : 5x to 25x(Continuous Zoom)

Eye Pieces                   : 10x / 15x Dioptric Adjustment

Objective Lens             : F=200 mm

Field of View               : 50mm

IPD Adjustment            : 55mm to 75mm

Fine Focusing             : By Motorized Foot Control



Illumination                 : 15V/150W twin Halogen Lamps with

100% coaxial through the lenses

focused Fiber optics light guide 1.5

meter, white bright light more than

80,000 Lux when maximum.



Field of Illumination    : 70mm

Filter                            : Cobalt Blue, Green



Arm                              : Counter balanced pantographic

arm with 320 degree rotation.

Vertical Range of Counter

Balanced Arm: 250mm to 300mm



Floor Stand                  : Mobile floor stand on caster wheels

for easy handling and absolute stability.



Base                            : 600mm x 500mm (Approx)

Height                          : 1500mm (Approx.)

Weight                         : 65kg (Approx.)

Power                         : AC 220V, 50/60Hz.



Spares: Dust Cover for covering the microscope,  Set of sterilizable of Silicon Caps, 15v-150w Bulbs, Fuses.

OPTIONAL ACCESSORIES:-
1. Beam Splitter with Camera Mount
2. CCD Camera
