Thermal label printer clothing label printer
- 30 Set / Sets per Month
- Xiamen
- screen printing machines for water film transfer films
- Screen printing machinery ,transparent film,thermal transfer paper,water labeling,ceramic decals
- Automatic sceen printer,PVC,PET films printing machine,automatic silk screen printer
- Roll to roll screen printer of heat transfer paper
- PET PVC film screen printing press
- Roll to roll screen printer of transfer films,paper ,ceramic transfer paper
Product Details
Condition: | New | Place of Origin: | Fujian, China | Brand Name: | Lingtie |
Model Number: | LTA-460 | Usage: | Label Printer, Paper Printer | Automatic Grade: | Automatic |
Voltage: | 220V | Gross Power: | 3kw | Dimensions(L*W*H): | L2850 x W1000 x H1760 mm |
Weight: | 1000kg | Certification: | ISO 9001 | Warranty: | One year and life maintenance |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Model No. | LTA-460 | Printing material thickness | 0.02-0.5 mm |
Screen Frame Area | 700x870mm | Squeegee angle | 0-30° |
Max. Print Area | 460x560mm | Frame regulating variable | 60 mm |
Max. Paper Width | 470mm | Bench height | 980 mm |
Printing Speed | 20-70 t/min | Height of screen frame |
|
Power | Main Drive Motor | 0.75kw | |
Pulling Drive Motor | 1.5 kw | ||
Air Suction Motor | 0.7kw | ||
UV Drier UV | 5.5x2kw (optional) | ||
Machine Weight | Net Weight | 1000kg | |
Gross Weight | 1200kg | ||
Power | 220V 3KW (single-phase power) | ||
Remark: can be designed against your need | |||
Machine Size | L2850 x W1000 x H1760 mm | ||
Packing size | L2950 x W1100 x H1630 mm |
1,Our machine adopt the best CNC built-in computer control system, running stability high precision, long life, high speed responsibility, high torque.
2,Magic eye imports from Germany, the sensor precision is adjustable and it is good for color match and accurate register of printing.
3,Frequency converter & adjusting device adopts Mitsubishi brand (Japan) regulate speed electrically, which is featured by easy operation, steady rotation, safety and correctness.
4,The electronic counter can preciously control the carton quantity.
5,Photo sensor auto-detection system for no films.
6,The machine has QC lamps, easy to operate.
7,The suction air can be adjusted discretionarily and intermittently. The machine adopts suction ventilator and avoids any scratch on printing surface and keeps the constant tensile force.
8,Both side of squeegee can be used, and extend the useful time.
9,Work table adopts stainless steel, never rust, anti dumping design, safety and reasonable.
10,The machine adopts electrostatic painting and stoving varnish and solvent-resistance on the surface.
11,High quality fitting, ensure the printing precision and stable running.
12,By using wheel on the screen printing machine, easy to move and other humanity design.
13,Suit for printing large impression, fine words, mesh point, the products is clear, bright and don’t fade in color.
14,Ink good adhesion, ink layer thickness, don’t fade in color, no fade, and design stereo feeling good, bright in color.
15,High printing speed, replace the traditional manual, semiautomatic operation modes, improve the production efficiency more than six times. Only need one people to operate.
16,This machine can be connected to UV drier, die-cutting machine, slitting machine, rewinder etc.
Printing materials:
PVC,PET,PP,PC,PE,BOPP etc all kinds of films, various of nameplate for electronic appliances, membrane switches, panels, soft circuit board, IMD,IML,FPC,rubber vulcanization,heat transfer films, non-woven fabric, color labels for cars, water labeling, ceramic decals, thermal transfer paper, leather, electrostatic film, tetoron, coated paper, adhesive sticker and so on. The thinnest which it can be printing is 0.02 mm.
Row material →Automatic feeding machine (double-sided dedusting,removing film,electrostatic eliminating)→Automatic printing ( automatic punching, printing, QC, automatic feeding )→Automatic oven (be self-polishing , protective film, attach tape, release paper ) →Automatic receiving →Automatic punching machine( cut)→End product.
Q: Are you manufactory or trade company?
A: We are the manufactory in Xiamen,Fujian province,China
Q: Can you make particular design according to our requirements?
A: Yes,we can make a special change according to your requirement.
Q: What’s the covering area of complete equipment,and how many worker for the whole process?
A: About 7 minters length 3 minters width,only 1-2 people to operate. directly save costs.
O: What’s the speed of your equipment?
A: 20-70 print per minute(about 20 meters), about 3000 papers/hour. More than 6 times of production efficiency than semi-automatic.
Q: What are your payment terms?
A : 30% deposit and balance T/T against copy of Bill of Landing or L/C at sight.
Q; Where certificate can you pass?
A:CE, IAF and ISO90001:2008.
Q: What is your company’s production capacity?
A: 30 Set/ Set/ Month
1,We have a rich experience,technical good,service awareness ahead of the professional team, can be timely and effective solve the problem for you.
2,Installation and debug machine for you without any charge.Also,giving a technical training for your employees.
3,All of our machines can have one year guarantee and lifelong maintenance.
4,We can also provide you with printing materials, printing ink and solvents and other raw materials.
