CWDM Filter for CATV Triple Play

Name: CWDM Filter for CATV Triple Play
Brand: LINKET
Availability: InStock

FOB Price

USD $20 - $58 / Piece

2 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	LINKET
Model Number	1310/1490/1550nm Filter WDM

1. Why choose LINKET ?

----- Our customers: FiberHome, Fujikura, HUAMAI, KEXIN, FOCI, Sunsea, TD Telecom

----- Largest PLC Splitter Manufacturer in China: 10Kpcs/day, 40% market share

----- Most Professional on Key Technology: Wafer Dicing and Coupling

----- Import wafer only from South Korea and Reliable relationship with wafer suppliers

----- Direct Factory Price

2. Technical Specs for FWDM

Parameter			Unit	Value
Central Wavelength			nm	850/1310	980/1550	1310/1550	1480/ 1550	1310/1490/1550	C/L Band	1310/1625	1550/1625
Wavelength	Type 1	Passband	nm	850±50	980±40	1310±40	1450~1490	1310±40 1490±10	1528~1563	1310±40	1550±40
		Reflective Band		1310±50	1550±40	1550±40	1530~1580	1530~1580	1570~1610	1625±10	1625±10
	Type 2	Passband		1310±50	1550±40	1550±40	1530~1580	1530~1580	1570~1610	1625±10	1625±10
		Reflective Band		850±50	980±40	1310±40	1450~1490	1310±40	1490±10 1528~1563	1310±40	1550±40
Insertion Loss	Pass Channel		dB	≤0.6
	Reflective Channel			≤0.4
Isolation	Pass Channel		nm	Standard ISO≥30, High ISO≥40
	Reflective Channel			Standard ISO≥13, High ISO≥18
Flatness			dB	≤0.3
Directivity			dB	≥50
Return Loss			dB	≥45
PMD			ps	≤0.10
PDL			dB	≤0.10
Insertion Loss Temperature Sensitivity			dB/°C	≤0.005
Wavelength Temperature Shifting			nm/°C	≤0.002
Fiber Type			-	50/125 or 62.5/125 Multimode fiber, SMF-28e Single mode fiber, HI1060 Fiber
Max. Power Handling			mW	≤500
Operation Temperature			°C	-10~+70
Storage Temperature			°C	-40~+85
Package Dimension			mm	Φ5.5×34 (Φ0.25 fiber), Φ5.5×38(Φ0.9 fiber)

3.Packaging

4. Different Models

Changzhou LINKET Electronics Technology Co., Ltd.: Contact nameStephanie Shen
Chat Now; Phone86-519-86221538; AddressLongwo Rd 3# , Wujin South High-Tech Zone, Changzhou ,China., Changzhou, Jiangsu

Production/Manufatcurer Level	Cut Wafer and Produce Chips	Make V-Groove	Make Fiber Array	Coupling	Produce Patch Cords and Install Connector
1st Level (LINKET)	√	√	√	√	√
2nd Level		√	√	√	√
3rd Level			√	√	√
4th Level				√	√
5th Level					√
LINKET intergrates the total chain, is the top-level PLC Splitter manufacturer in China. With over 10K/day production capacity, our PLC Splitters occupy over 40% market share in China.
