horizontal belt conveyor (86-15978436639)

FOB Price

USD $150 - $550 / Set

1 Set(Min.Order)

Supply Ability 1000 Meter / Meters per Month
Port Qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Slat Conveyor	Material:	Rubber
Material Feature:	Heat Resistant	Structure:	Belt Conveyor	Load Capacity:	Min: 40-80t/h Max: 655-1284t/h
Place of Origin:	Henan, China	Brand Name:	HC	Model Number:	HC series

Product Description

Horizontal belt conveyor

Introduction:

Horizontal Belt Conveyor is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force. The Belt Conveyor is advanced and simple in structure, easy to maintain. Its transfer capacity is high, transfer distance is long

Technical parameters:

Belt width ( mm )	Convey length (m) / power (Kw)			Speed(M/S)	Capacity(t/h)
400	≤12 / 1.5	12-20 / 2.2-4	20-25 / 3.5-7.5	1.3-1.6	40-80
500	≤12 / 3	12-20 /4-5.5	20-30 / 5.5-7.5	1.3-1.6	78-191
650	≤12 / 4	12-20 / 5.5	20-30 / 7.5-11	1.3.-16	131-323
800	≤6 / 4	6-15 /5.5	15-30 /7.5-15	1.3-1.6	278-546
1000	≤10 / 5.5	10-20 / 7.5-11	20-40 / 11-12	1.3-2.0	435-853
1200	≤10 / 7.5	10-20 /11	20-40 / 15-30	1.3-2.0	655-1284

Accessory:

1. The conveying quantity is worked out by the following conditions: material density is between 1.0t/m3-1.6t/m3; conveyor obliquity is less than 18o and the material stockpile angle is 30o.

2. Density of material is less than 2.5t/m3.

3. The conveying length is not restricted to the form; different length can be manufactured according to customers demands.
