1080p 1/3" CMOS Super wide dynamic ICR Vanderproof Infrared cctv CCTV Surveillance Video Security System AHD Zoom Camera CCTV Varifocal Lens 30M Infrared Distance AHD Dome camera
AHD Dome camer Features:
1080p 1/3" CMOS
2.8-12mm 2.0MP VF lens
36pcs IR leds
30-40m IR range
Super wide dynamic ICR
Vanderproof Infrared IR dome camera
CCTV AHD Dome Camera Technical Specifications:
Imaging Sensor | 1/3” 2.43Mega Progressive Scan CMOS IMX222 |
Signal System | PAL/NTSC |
Pixel | 1984(H)×1225(V) |
Minimum Illumination | 0.001Lux @ (F1.2,AGC ON),0 Lux with IR 0.0014Lux @ (F1.4,AGC ON),0 Lux with IR |
Shutter speed | PAL: 1/50s-1/100,000s- NTSC: 1/60 s- 1/100,000s |
Lens | 2.8~12mm@ F1.4 |
Len type | Φ14 |
D/N Switch | ICR Infrared filter |
Horizontal resolution | 1100TVL |
Angle adjust | H:0°~355°;V:0°~80°;rotation: 0°~90° |
Synchronization System | Internal Synchronization |
Frame rate | 1080p@25fps/1080p@30fps |
Video Output | AHD Video(1080P) |
S/N Ratio | More than 80dB |
Title setting | on/off (15 characters, Any position on the Screen) |
AGC | support |
Color/black white | Auto/Color/B/W/External Control |
White Balance | Auto |
Privacy Zone | 1~8 Zones |
Mobile detection | 1~4 Zones |
Backlight Compensation | Support |
Language | Chinese/English/German / French / Italian / Spanish / Polish / Russian / Turkish / Portuguese / Dutch/Turkish |
Function | AHD 1080P output,With digital wide dynamic, fog, light suppression / motion detection / privacy,2D/3D noise reduce and etc. |
Scene | indoor,low luxindoor lightoutdoor |
Temperature and humidity | -20℃~65℃,humidity<90%(No condensation) |
Power | DC12V±15%(“-A supportAC24V±15% / DC12V±15%) |
IR distance | 30-40m |
consumption | 4W MAX(-A: 5W MAX) |
Waterproof | IP66 |
Communication | Coaxial video control coaxial output control protocol: CVBS protocol: Pelco-C output control (with controller) |
