magnetic stripe card reader head

FOB Price

Negotiable / Piece

500 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	2M
Model Number	2M-3RF

2-, 3-track low profile read head series used in POS (point of sales),

2-, 3-track low profile read head series used in POS (point of sales), magnetic card readers/writers, credit/debit cards

2-, 3-track low profile read head series used in POS (point of sales), magnetic card readers/writers, credit/debit cards
2M-2RLPXX-1 series (2-track low profile read head series):
- Outline dimensions: 11.0mm x 8.0mm (L x W)
- Head height: 5.0mm
- 2M-3RLPXX-1 series (3-track low profile read head series):
  - Outline dimensions: 11.8mm x 11.0mm (L x W)
  - Head height: 5.0mm
  - Main parameters include inductance, DC resistance, gap width and more. Adjustable as follows:
  - Inductance from 25 mH to 110 mH
  - DC resistance from 100 ohm to 350 ohm
- Normal lifetime (500,000 times) and long-lifetime (more than 1,000,000 times) technology support (sendust).
- We supply several mounting brackets for 2-, 3-track low profile heads,also we can supply mounting brackets in accordance with customers requirements.
