Ground source heat pump R134A 140kw-2300kw

Specifications

Ground Source Heat Pump R134A
LCD panel controller, stable performance, energy saving, environment friendly

Ground Source Heat Pump R134A, water source heat pump

STRUCTURE

Panels and frame are made from galvanized steel protected with polyester powder painting to ensure total resistance to atmospheric agents.

HERMETIC COMPRESSORS

Single phase rotary type (mod.10÷35),3-phase (mod.40÷150) scroll type compressors, with built-in thermal overload cut-out and crankcase heater, mounted on rubber vibration dampers.Mod. 40÷60 are available with single phase compressors.



FEATURES

l      13 sizes available ranging from 330 kW to 3350 kW cooling capacity.

l      Wide application as hotel, apartment, villa, factory, shopping center, office building, school, etc.

l      Semi-hermetic screw compressor for the whole range. Each compressor is equipped with a crankcase heater and a built-in electronic protection with temperature sensor located directly in the motor winding and on the discharge line.

l      The refrigerant circuit is complete with sight glass, filter drier, high and low pressure gauges, solenoid valve, electronic expansion valve, high and low pressure switch.

l      Shell and tube dry expansion type condenser, factory insulated with flexible close cell material.

Flooded type shell and tube evaporator, higher efficiency less water consumption, easy maintenance and cleaning.

l      The electric panel consists of compressor breaker, compressor contactor, phase sequence relay, control circuit breaker, microprocessor control with function display.

l      LCD display, touch screen control panel as standard.

l      Automatic operation dramatically reducing maintenance cost thanks to reliable microprocessor system.

l      An infinitely variable capacity control system that is capable of exactly matching the demand requirement of the system is to be supplied. This system is to provide precise and stable control of supply water temperature over the complete range of operating conditions.

OPTIONAL

l      Desuperheater as optional.

Electronic controller with BMS system.
