Ultra-High Temperature Ground Source Heat Pump

Specifications

GSHP 200-2400G1
Cooling capacity: 111-1333 kW
Heating capacity: 200-2400 kW

19 sizes available ranging from 200 kW to 2400 kW

heating capacity.

 Great environmental and economic benefit: no boiler or

cooling tower; less space, less CO2 and less initial

investment.

 Acting as multi-function unit such as cooling, heating,

sanitary hot water separately or simultaneously.

 Using energy from low temperature geothermic source,

oil sewage, steel-making sewage, city sewage, etc.

 Semi-hermetic screw compressor for mod. 200÷2400.

Each compressor is equipped with a crankcase heater

and a thermal overload cut-out; the screw compressor

is also complete with a built-in electronic protection with

temperature sensor located directly in the motor

winding and on the discharge line.

 The refrigerant circuit is complete with sight glass, filter

drier, high and low pressure gauges, electronic

expansion valve, high and low pressure switch.

 Shell and tube dry expansion type condenser, factory

insulated with flexible close cell material.

 Shell and tube type evaporator, factory insulated with

flexible close cell material.

 The electric panel consists of compressor breaker,

compressor contactor, phase sequence relay, control

circuit breaker, microprocessor control with function

display.

 LCD display, touch screen control panel as standard.

 Automatic operation dramatically reducing maintenance

cost thanks to reliable microprocessor system.

 For the units with semi-hermetic screw compressor, an

infinitely variable capacity control system that is capable

of exactly matching the demand requirement of the

system is to be supplied. This system is to provide

precise and stable control of supply water temperature

over the complete range of operating conditions.
