RV-701WS 12V car wireless reversing camera with rearview mirror for sales

Specifications

RV-701WS rearview mirror wireless camera
7inch mirror monitor with wireless video receiver
CMOS/CCD camera
CE RoHS certificat

RV-701WS 12V car wireless reversing camera with rearview mirror for sales

Simple Feature:

Wireless rear view system for truck/vans/buses/etc.
7inch monitor with wireless receiver built in
High resolution camera with wireless transmitter built in
100M open air reception and transmission



7" Wireless rear view mirror monitor
Built in wireless 2.4GHz VIDEO Receiver
Wireless AUDIO optional
Ratio: 16:9 /4:3
Pixel: 800*480
Video input: 2 way
Backup: V2 auto reverse
View angle: U/D/L/R
Power supply: DC12V, 11-32V optional
Current: 0.7A
Luminance: 300-400/m2
Operating temp.:-10°C ~ 60°C
Installation:clip on existing mirror



Wireless Camera Spec
Wireless camera with built in 2.4GHz VIDEO Transmitter
Wireless AUDIO optional
ImageSensors: 1/3", 1/4" CMOS/CCD camera optional
TV System:PAL / NTSC
waterproof rate:Ip67
Effective Pixels:512 x 582 pixels / 512 x 492 pixels
752x582 pixels / 768×494 pixels
Resolution:420TV lines
Minimum Illumination:1.0Lux / F1.2  0.2Lux / F1.2 (0Lux IR ON)
Pin Lens:f=2.8mm / F = 2.0
Lens Angle:120°
Vertical Sync. Frequency:50Hz / 60Hz
Video Output:1.0vp-p, 75Ohm
Power Supply:DC12V, DC 11-32V optional
Current Consumption: ≤ 300mA



Packaging included:
7inch mirror monitor x 1
Stand bracket x 1
1/4" sharp CCD camera x 1
20m water resistant cable as alternative optional
