Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > 24 Core Electric Cable

24 Core Electric Cable

Name: 24 Core Electric Cable
Brand: YUFENG
SKU: 104163459
Availability: InStock

Chongqing Yufeng Wire & Cable Co., Ltd.

Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Chongqing, China

Brand Name:

YUFENG

Model Number:

Low/Medium Voltage

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Chongqing / Shanghai / Guangzhou / Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Chongqing, China

Brand Name YUFENG

Model Number Low/Medium Voltage

Type Insulated

Application Overhead

Conductor Material Copper

Conductor Type Solid

Insulation Material PVC

Cable

Specifications

Type:Low/Medium/High Voltage

Color: Black

Certification:UL,CE,ROHS,CCC,ISO9001,ISO14001,ASG CNAS

Specifications

Power Cable

XLPE Type		Name	Application
Cu	Al
Conductor	Conductor
YJV	YJLV	XLPE Insulated, PVC or PE Sheathed Power Cable	For lying indoor, channel and underground. Unable to bear external mechanical force, but bear the traction force during lay.
YJV	YJLV
YJV₂₂	YJLV₂₂	XLPE Insulated, Steel Tape Armored, PVC or PE Sheathed Power Cable	For laying indoor, tunnel, channel and underground. Able to bear external mechanical force, but unable to bear large pulling force.
YJV₂₃	YJLV₂₃

YJV₃₂	YJLV₃₂	XLPE Insulated, Fine Steel Wire Armored, PVC or PE Sheathed Power Cable	For lying in shave with large difference of level. Able to bear external mechanical force, and moderate pulling force.
YJV₃₃	YJLV₃₃
YJV₄₂	YJLV₄₂	XLPE Insulated, Thick Steel Wire Armored, PVC or PE Sheathed Power Cable	Able to bear positive pressure and pulling force

Type	No . of cores	Rated voltage(KV)
		0.6/1	1.8/3	3.6/6	6/6 6/10	8.7/10 8.7/15
		Nominal area of conductor (mm2)
YJV YJLV YJV22 YJLV22 YJV32 YJLV32	1,2,3, 3 1, 3 2, 4 1, 5	1.5-630	10-400	25-400	25-400	25-400

YJV,YJV-6/6kv 6/10kv XLPE Insulated Power Cable
Nominal Cross Sectional Area(mm²)	Thickness of Insulated(mm)	Thickness of Outer Sleath (mm)	Diameter of Overall Approx.(mm)	Weight of Cable Cu Approx.(kg/km)	Weight of Cable AL Approx.(kg/km)	Conductor DC resistance CU Approx.(Ω/km)	Conductor DC resistance AL Approx.(Ω/km)	Testing Volts(kv/5min)	Current Carring Capacity In Air CU (A)	Current Carring Capacity In Air AL (A)	Current Carring Capacity In Ground CU (A)	Current Carring Capacity In Ground AL (A)
1×25	3.4	2	20	598	443	≤0.727	≤1.20	21	190	145	210	160
1×35	3.4	2	22	719	502	≤0.524	≤0.868	21	230	180	250	195
1×50	3.4	2	23	884	575	≤0.387	≤0.641	21	275	215	300	230
1×70	3.4	2	24	1097	664	≤0.268	≤0.443	21	345	265	370	285
1×95	3.4	2	26	1378	790	≤0.193	≤0.320	21	415	325	445	345
1×120	3.4	2	28	1658	916	≤0.153	≤0.253	21	480	375	505	395
1×150	3.4	2	30	1967	1038	≤0.124	≤0.206	21	550	425	575	445
1×185	3.4	2	31	2335	1190	≤0.0991	≤0.164	21	635	490	650	500
1×240	3.4	2	34	2908	1423	≤0.0754	≤0.125	21	745	580	760	590
1×300	3.4	2	36	3507	1650	≤0.0601	≤0.100	21	860	665	870	670
1×400	3.4	2.5	39	4503	2027	≤0.0470	≤0.0778	21	1010	785	1000	780
1×500	3.4	2.5	42	5479	2384	≤0.0366	≤0.060	21	1180	910	1150	895
1×630	3.4	2.5	48	6952	3046	≤0.0283	≤0.0469	21	1330	1060	1280	1016
1×800	3.4	2.6	52	7120	3575	≤0.0221	≤0.0367	21	1530	1230	1430	1160
1×1000	3.4	2.8	57	10500	4300	≤0.0176	≤0.0291	21	1720	1410	1595	1300
1×1200	3.4	2.9	61	12426	4986	≤0.0151	≤0.0247	21	1876	1540	1695	1410
3×25	3.4	2.5	42	895	1430	≤0.727	≤1.20	21	145	110	140	110
3×35	3.4	2.5	44	2293	1640	≤0.524	≤0.868	21	175	130	170	130
3×50	3.4	2.5	46	2812	1881	≤0.387	≤0.641	21	205	160	200	155
3×70	3.4	3	50	3508	2205	≤0.268	≤0.443	21	255	195	245	155
3×95	3.4	3	54	4402	2653	≤0.193	≤0.320	21	310	235	290	190
3×120	3.4	3	58	5319	3087	≤0.153	≤0.253	21	350	275	330	225
3×150	3.4	3	62	6309	3518	≤0.124	≤0.206	21	400	310	370	225
3×185	3.4	3	65	7319	3877	≤0.0991	≤0.164	21	455	355	420	325
3×240	3.4	3.5	71	9218	4753	≤0.0754	≤0.125	21	530	415	480	380
3×300	3.4	3.5	75	11159	5577	≤0.0601	≤0.1005	21	605	475	545	430
3×400	3.4	3.7	84	15107	7547	≤0.0470	≤0.0778	21	705	555	625	485

YJV,YJV-8.7/10kv 8.7/15kv XLPE Insulated Power Cable
Nominal Cross Sectional Area(mm²)	Thickness of Insulated(mm)	Thickness of Outer Sleath (mm)	Diameter of Overall Approx.(mm)	Weight of Cable Cu Approx.(kg/km)	Weight of Cable AL Approx.(kg/km)	Conductor DC resistance CU Approx.(Ω/km)	Conductor DC resistance AL Approx.(Ω/km)	Testing Volts(kv/5min)	Current Carring Capacity In Air CU (A)	Current Carring Capacity In Air AL (A)	Current Carring Capacity In Ground CU (A)	Current Carring Capacity In Ground AL (A)
1×25	4.5	1.8	23	680	525	≤0.727	≤1.20	30.5	190	145	210	160
1×35	4.5	1.8	24	804	587	≤0.524	≤0.868	30.5	230	180	250	195
1×50	4.5	1.9	25	984	674	≤0.387	≤0.641	30.5	275	215	300	230
1×70	4.5	1.9	27	1201	768	≤0.268	≤0.443	30.5	345	265	370	285
1×95	4.5	2	29	1490	902	≤0.193	≤0.320	30.5	415	325	445	345
1×120	4.5	2	30	1765	1022	≤0.153	≤0.253	30.5	480	375	505	395
1×150	4.5	2.1	32	2091	1162	≤0.124	≤0.206	30.5	550	425	575	445
1×185	4.5	2.1	34	2452	1307	≤0.0991	≤0.164	30.5	635	490	650	500
1×240	4.5	2.2	36	3034	1548	≤0.0754	≤0.125	30.5	745	580	760	590
1×300	4.5	2.4	39	3672	1815	≤0.0601	≤0.100	30.5	860	665	870	670
1×400	4.5	2.4	42	4646	2170	≤0.0470	≤0.0778	30.5	1010	785	1000	780
1×500	4.5	2.5	45	5651	2556	≤0.0366	≤0.060	30.5	1180	910	1150	895
1×630	4.5	2.5	50	7154	3248	≤0.0283	≤0.0469	30.5	1330	1060	1280	1016
1×800	4.5	2.7	55	8750	3790	≤0.0221	≤0.0367	30.5	1530	1230	1430	1160
1×1000	4.5	2.9	59	10727	4527	≤0.0176	≤0.0291	30.5	1720	1410	1595	1300
1×1200	4.5	3	63	12642	5202	≤0.0151	≤0.0247	30.5	1876	1540	1695	1410
3×25	4.5	2.8	50	2573	2072	≤0.727	≤1.20	30.5	145	110	140	110
3×35	4.5	2.9	53	2985	2334	≤0.524	≤0.868	30.5	175	130	170	130
3×50	4.5	2.9	55	3529	2598	≤0.387	≤0.641	30.5	205	160	200	155
3×70	4.5	2.9	58	4197	2895	≤0.268	≤0.443	30.5	255	195	245	190
3×95	4.5	3.3	63	5230	3462	≤0.193	≤0.320	30.5	310	235	290	225
3×120	4.5	3.3	66	6120	3888	≤0.153	≤0.253	30.5	350	275	330	255
3×150	4.5	3.6	70	7207	4416	≤0.124	≤0.206	30.5	400	310	370	225
3×185	4.5	3.6	74	8378	4935	≤0.0991	≤0.164	30.5	455	355	420	325
3×240	4.5	3.6	79	10177	5712	≤0.0754	≤0.125	30.5	530	415	480	380
3×300	4.5	3.8	84	12159	6577	≤0.0601	≤0.1005	30.5	605	475	545	430
3×400	4.5	3.9	89	15641	8081	≤0.0470	≤0.0778	30.5	705	555	625	485

YJV,YJV-12/20kv XLPE Insulated Power Cable
Nominal Cross Sectional Area(mm²)	Thickness of Insulated(mm)	Thickness of Outer Sleath (mm)	Diameter of Overall Approx.(mm)	Weight of Cable Cu Approx.(kg/km)	Weight of Cable AL Approx.(kg/km)	Conductor DC resistance CU Approx.(Ω/km)	Conductor DC resistance AL Approx.(Ω/km)	Testing Volts(kv/5min)	Current Carring Capacity In Air CU (A)	Current Carring Capacity In Air AL (A)	Current Carring Capacity In Ground CU (A)	Current Carring Capacity In Ground AL (A)
1×35	5.5	2	27	979	762	≤0.524	≤0.868	42	230	180	250	195
1×50	5.5	2	29	1155	846	≤0.387	≤0.641	42	275	215	295	225
1×70	5.5	2	30	1393	959	≤0.268	≤0.443	42	340	265	360	280
1×95	5.5	2	32	1681	1093	≤0.193	≤0.320	42	415	325	440	340
1×120	5.5	2	34	1979	1236	≤0.153	≤0.253	42	480	370	495	385
1×150	5.5	2	35	2301	1373	≤0.124	≤0.206	42	550	420	560	435
1×185	5.5	2	38	2718	1573	≤0.0991	≤0.164	42	630	485	640	495
1×240	5.5	2.5	40	3302	1817	≤0.0754	≤0.125	42	745	575	750	580
1×300	5.5	2.5	43	3941	2084	≤0.0601	≤0.100	42	860	660	855	660
1×400	5.5	2.5	45	4931	2455	≤0.0470	≤0.0778	42	1000	775	980	765
1×500	5.5	2.5	48	5956	2861	≤0.0366	≤0.0605	42	1160	890	1140	885
1×630	5.5	2.6	49	7769	3863	≤0.0283	≤0.0469	42	1330	1060	1280	1010
1×800	5.5	2.8	57	8945	3985	≤0.0221	≤0.0367	42	1530	1230	1430	1160
1×1000	5.5	2.9	61	10918	4718	≤0.0176	≤0.0291	42	1720	1410	1595	1300
1×1200	5.5	3.1	65	12900	5460	≤0.0151	≤0.0247	42	1876	1540	1695	1410
3×35	5.5	3	57	3348	2696	≤0.524	≤0.868	42	175	130	170	130
3×50	5.5	3	60	3904	2973	≤0.387	≤0.641	42	205	160	200	155
3×70	5.5	3	63	4623	3321	≤0.268	≤0.443	42	255	195	245	190
3×95	5.5	3.5	67	5593	3825	≤0.193	≤0.320	42	310	240	290	225
3×120	5.5	3.5	71	6495	4262	≤0.153	≤0.253	42	350	275	330	225
3×150	5.5	3.5	74	7637	4846	≤0.124	≤0.206	42	400	310	370	325
3×185	5.5	3.5	78	8803	5361	≤0.0991	≤0.164	42	455	355	415	380
3×240	5.5	3.5	84	10729	6263	≤0.0754	≤0.125	42	535	420	480	430
3×300	5.5	4	89	12723	7141	≤0.0601	≤0.100	42	610	475	545	490
3×400	5.5	4.1	96	16207	8647	≤0.0470	≤0.0778	42	705	555	625	485

YJV,YJV-21/35kv XLPE Insulated Power Cable
Nominal Cross Sectional Area(mm²)	Thickness of Insulated(mm)	Thickness of Outer Sleath (mm)	Diameter of Overall Approx.(mm)	Weight of Cable Cu Approx.(kg/km)	Weight of Cable AL Approx.(kg/km)	Conductor DC resistance CU Approx.(Ω/km)	Conductor DC resistance AL Approx.(Ω/km)	Testing Volts(kv/5min)	Current Carring Capacity In Air CU (A)	Current Carring Capacity In Air AL (A)	Current Carring Capacity In Ground CU (A)	Current Carring Capacity In Ground AL (A)
1×95	9.3	2.5	40	2193	1605	≤0.193	≤0.320	73.5	415	320	420	325
1×120	9.3	2.5	42	2498	1756	≤0.153	≤0.253	73.5	475	370	480	370
1×150	9.3	2.5	44	2830	1910	≤0.124	≤0.206	73.5	540	420	540	420
1×185	9.3	2.5	45	3248	2102	≤0.0991	≤0.164	73.5	620	480	620	480
1×240	9.3	2.5	48	3881	2395	≤0.0754	≤0.125	73.5	730	565	725	560
1×300	9.3	3	50	4529	2672	≤0.0601	≤0.100	73.5	840	650	830	640
1×400	9.3	3	53	5570	3094	≤0.0470	≤0.0778	73.5	995	780	970	760
1×500	9.3	3	55	6690	3595	≤0.0366	≤0.0605	73.5	1160	915	1130	875
1×630	9.3	3.1	60	8099	4193	≤0.0283	≤0.0469	73.5	1290	1030	1260	990
1×800	9.3	3.1	65	9752	4792	≤0.0221	≤0.0367	73.5	1480	1180	1430	1140
1×1000	9.3	3.2	70	11781	5581	≤0.0176	≤0.0291	73.5	1660	1350	1570	1280
1×1200	9.3	3.3	74	13784	6344	≤0.0151	≤0.0247	73.5	1810	1500	1720	1390

YJV,YJV-26/35kv XLPE Insulated Power Cable
Nominal Cross Sectional Area(mm²)	Thickness of Insulated(mm)	Thickness of Outer Sleath (mm)	Diameter of Overall Approx.(mm)	Weight of Cable Cu Approx.(kg/km)	Weight of Cable AL Approx.(kg/km)	Conductor DC resistance CU Approx.(Ω/km)	Conductor DC resistance AL Approx.(Ω/km)	Testing Volts(kv/5min)	Current Carring Capacity In Air CU (A)	Current Carring Capacity In Air AL (A)	Current Carring Capacity In Ground CU (A)	Current Carring Capacity In Ground AL (A)
1×50	10.5	2.2	39	1758	1449	≤0.387	≤0.641	91	275	210	285	220
1×70	10.5	2.4	41	2038	1604	≤0.268	≤0.443	91	340	265	350	270
1×95	10.5	2.4	43	2355	1767	≤0.193	≤0.320	91	415	320	420	325
1×120	10.5	2.4	44	2666	1923	≤0.153	≤0.253	91	475	370	480	370
1×150	10.5	2.5	46	3031	2103	≤0.124	≤0.206	91	540	420	540	420
1×185	10.5	2.5	48	3427	2282	≤0.0991	≤0.164	91	620	480	620	480
1×240	10.5	2.6	50	4070	2584	≤0.0754	≤0.125	91	730	565	725	560
1×300	10.5	2.7	53	4748	2891	≤0.0601	≤0.100	91	840	650	830	640
1×400	10.5	2.8	56	5801	3325	≤0.0470	≤0.0778	91	995	780	970	760
1×500	10.5	2.9	59	6623	4076	≤0.0366	≤0.0605	91	1160	915	1130	875
1×630	10.5	3	63	8211	4305	≤0.0283	≤0.0469	91	1290	1030	1260	990
1×800	10.5	3.1	68	10014	5054	≤0.0221	≤0.0367	91	1480	1180	1430	1140
1×1000	10.5	3.3	72	12078	5878	≤0.0176	≤0.0291	91	1660	1350	1570	1280
1×1200	10.5	3.4	76	14100	6657	≤0.0151	≤0.0247	91	1810	1500	1720	1390
3×50	10.5	3.4	81	6728	5778	≤0.387	≤0.641	91	189	152	168	144
3×70	10.5	3.5	84	7581	6232	≤0.268	≤0.443	91	244	189	223	177
3×95	10.5	3.6	88	8630	6824	≤0.193	≤0.320	91	295	225	270	200
3×120	10.5	3.8	93	9688	7406	≤0.153	≤0.253	91	331	258	307	237
3×150	5.5	3.9	96	11017	8165	≤0.124	≤0.206	91	377	290	344	265
3×185	10.5	4	100	12390	8904	≤0.0991	≤0.164	91	400	310	385	295
3×240	10.5	4.1	105	14427	9863	≤0.0754	≤0.125	91	470	365	445	345
3×300	10.5	4.4	108	15940	10270	≤0.0601	≤0.100	91	545	425	505	390
3×400	10.5	4.5	116	19346	11786	≤0.0470	≤0.0778	91	635	490	575	450
