Smart Locker Digital RFID Sauna Lock

Specifications

1.Work with iB/TM card
2.Low voltage alarm
3.Low energy consumpition
4.CE,FCC certificated
5.For Sauna/Hotel/School/Spa

Specification

Model: 3000DL,   Smart Locker Digital RFID Sauna Lock



1.Work with iB/TM key
2.Low voltage alarm
3.Low energy consumpition
4.CE,FCC certificated

5. Keypad Digital Locker Lock For Lockers For Sauna/Hotel/School/Spa



Features



4-Lever Managemen   Smart Locker Digital RFID Sauna Lock

-1st lever: Owner Key(1 iB Card) is used to issue or delete Master Key or Master Code, and emergent opening

-2nd lever: Master Key(Max. 5 iB Cards) or Master Code (1 set) is used to issue or delete User Key or User Code, and servise opening

-3rd lever: User Key (1 iB card) or User Code(1 set) is for guest opening

Fault Tolerant Input

Any incorrect digits code can be input before inputting the correct code.

Hidden handle design

It's convenient for opening the door of cabinet.

External power backup

A 9V battery is for emergent power supply when internal batteries in low voltage.

Low power consumption

4 standard AA size alkaline batteries can last more than 16,000 cycles.

4 Working modes

4 working modes can be selected for the 3rd lever opening:

1. One-Time Code Opening

2. Permanent Code Opening

3. User Key opening

4. User Key + One-Time Code opening

Notifications with LED light and buzzer

In combination with LED and buzzer, notifies user any operations and errors.

Incorrect code alarm

Buzzer Alarm for 60sec after 4 incorrect attempts

Illegal Key Alarm

Buzzer Alarm for 60sec after 4 incorrect attempts with an illegal iB card

Anti-thief alarm(ATA)

Buzzer alarms for 60sec when latch be pressed or picked

Low-Voltage Alarm

Buzzer Alarm when unlocking under the voltage DC4.2V+/-0.2, notifies to replace new batteries.





Tech Index

Power Supply	DC4.5V, use of 3 pieces of AA batteries
Supply Voltage	Below DV4.5V with lack of voltage indications and can use about 200 more times.
Static Power Supply	<10u A
Dynamic Power Supply	< 150mA
Lifetime of battery	Normally can exceed 20,000 times and 200 more with low energy indication
Latch length	15mm
Door thickness	15-30mm
Working temperature	-20~+55
Lock types	4000EM,4000TM,2000EM,2000TM
Colors	Sliver

Shipment & Payment

MOQ	100 Pcs
Sample	Sample shipping within 48 hours after order
Packing detail	1pcs/white box, 40pcs/outer carton
	Carton size: 590*335*170mm
Bulk lead time	20 days after sample approval
Port of loading	Shenzhen



Our Manufacturing Advantages

1) Leading professional manufacturer of locker lock and electronic locks in China

2) High Security and Top Quality, Serious Quality Outlet ISO9001:2008

3) Monthly production capacity: 800,000pcs

4) OEM&ODM, small order available

5) Successful solution design various lock mechanism



Top Quality Digital Locker Lock Model 3000DL, Widely used in Cabinets or Lockers for Sauna, Hotel, Office Building, Factory, School, Gym.



Stainless Steel Material for Keypad



Work with iB or TM Card









Stainless Steel Material for Lock Body
