High Temperature Floor Mat Vulcanized Rubber Molding Press Machine/Auto Push-out Rubber Plate Curing With New Price
- 30 Set / Sets per Month
- Qingdao
- T/T
- PVC plate rubber vulcanizing machine/ Hydraulic hot press rubber mats vulcanizer/ vulcanizer
- Rubber Tile Vulcanizing press /rubber plate vulcanizer /rubber curing press machinery making slippers
- rubber slippers making machine Column type rubber tile plate vulcanizing press/rubber vulcanizer/rubber vulcanizing machine
- Rubber Vulcanizing Press, Vulcanizing Press, Plate Vulcanzing Press
- Portable conveyor belt hot vulcanizing machine/rubber vulcanizing machine
- New and old type Rubber Floor Tiles Making Machine / Rubber floor tiles vulcanizing press/Rubber Vulcanizer
Product Details
Condition: | New | Type: | Vulcanizer | Place of Origin: | Shandong, China |
Brand Name: | Qingdao Bojia | Model Number: | XLB series | Voltage: | depend your country |
Power(W): | 3KW | Dimension(L*W*H): | 2070*1050*2230 | Weight: | 1900KG |
Certification: | SGS/CE/ISO | Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. Superior Quality at Reasonable Price ;
2.One year warranty;
3.we are factory manufacture;
XLB-series electric heating full automatic molding seal ring oil pressure plate vulcanizing machine
Usage
XLB series plate vulcanizing machine is mainly used to suppress all kinds of rubber products and thermosetting plastic products.Also can be used as common hydraulic machine.
- Structure feathures
This XLB series plate vulcanizing machine is mainly consisted of main engine,hydraulic system and electronic control system.The oil cylinder will be fixed in the left side of the main engine alone in order to avoid the affection of the main engine's hot plate temperature.And that is conveninent for workers to operate with capacious vision.Hot plate temperature is controlled by temperature control table for its high precision and good quality.The machine's main parts are according to the ministry of chemical industry's standard which are made of high quality materials and processed elaborately.
- Technical parameters(Models of XLB-series plate vulcanizing machine)
Model
315T
250T
200T
160T
100T
50T
25T
Total pressure(KN)
3150
2500
2000
1600
1000
500
250
Max hydraulic pressure(KN)
16
20
16
16
16
16
16
Hot plate size(mm)
1200*1200
1000*1000
900*900
7500*850
600*600
400*400
350*350
Hot plate spacing(mm)
200
200
200
125
125
125
125
Working layer
2
2
2
2
2
2
2
Plunger stroke(mm)
500
500
500
500
300
250
250
Hot plate unit area pressure(KN)
2.2
2.5
2.5
2.5
2.8
3.12
2.04
Motor power(KW)
5.5
5.5
4
3
3
2.2
2.2
Overall dimension(mm)
1685*1320*2550
1780*1150*3634
1800*1200*2650
3000*1600*2523
2070*1050*2230
640*1470*400
570*1450*350
- Packing &Shipping
*Within 30days after receiving the deposit
*Standard export wooden paching container or as your demand
- Our service
*The guarantee period is one year;
*24 hours technical support;
*Offer lifetime service and spare parts;
*Technique training is free of charge.
Our company
Qingdao Bojia Machinery Manufacturing Co.,Ltd is one professional machinery manufacturer. Our company have one good and high quality design and manufacturing technology development group,often communicate with the customers and technology authority departments of rubber industry,constantly to improve and update our products which can meet the requirements of customers:Our company guarantee to provide you excellent pre-market sale and after sale service,timely technology information consulting,accessories and consumable parts supply etc,also can design and manufacture various non-standard products according to users requirements.
Our main products are:Conveying belt molding machine series:Batch off cooling machine series:Cushion cloth renovating machine series:open mixing mill series:Vulcanizing press series:Rubber cutting machine series:Rubber slitting machine series:Logitudinal cutting machine series:Conveyor belt machine series:Other rubber machines:Design and manufacturing of automatic production line.
Bojia machinery company always pursue”quality first,customer first”principle to offer high-quality products and excellent service,welcome new and old customers to visit our company.
