Welding Dual-use Generator Machine (KDE6500TW)

Wuxi Kaiao Power Machinery,Your Best Choice

Frequency (Hz): 50 60
Output power (KVA): 2 2.2

Voltage (V): 230 240
Current (A): 8.7 9.2
No-load welding voltageV: 72

Rated welding voltage V: 26-30
Rated welding DC A: 200
Current adjusting extension: 50-200
Electric welding load rate: 50%
Speed(r/min): 3000 3600
Phase: Single
Power factor: 1
Excitation system: (AVR) self-excited constant voltage
Noise level (7m) dB (A): 72

Fuel tank capacity (L): 15

Structure: Open frame
Panel: Ordinary
Output socket: Two
Output terminal post: Two
Net weight (kg): 105
Dimension (L*W*H)(mm): 640*480*530
Engine model: KA186FA
Engine type: Single-cylinder, vertical, air-cooled, direct injection
Bore*stroke (mm): 86 *72
Displacement (L): 0.418
Power (KW): 5.7/3000 6.3/3600
Fuel consumption rate (g. KW/h): 275.1 281.5
Compression ratio: 19
Lubrication system: Spring
Engine starting system: Type X: Recoil starter
Type E: Electric starter
Diesel oil model: Summer: 0#, winter: -10#
Lube oil model: SAE10W-30 (above CD grade)
Lube oil capacity (L): 1.65
Battery capacity(V-AH): 12V-36Ah
*A dual-use machine with excellent performance allows the customers low cost
*With the features of easy arc striking with steady electric arc, and convenient adjustment of welding current(adjusting extension: 50-200A), the machine is suitable for the electrode 2.0-4.0mm diameter, which allows easy operation.
Run steadily.Small size.Light.With wheel.Easy moved.Very convenice.Fuel-efficient
A dual-use machine with excellent performance allows the customers low cost.
