high quality galvanized mild steel chain
- 30 Ton / Tons per Month
- Qingdao Port
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Sail Rigging | |
| Model Number | TRANSPORT CHAIN ASTM80(G70) | Structure | Welded Chain | |
| Function | Conveyor Chain | Material | Alloy | |
| Standard or Nonstandard | Standard |
Product Description
Specifications
1.Material Carbon Steel2.Surface Self-color, E.Galv. , H.D.Galv.
3.Technology Forging&Casting
4.Surface: Polished
Lifting,Tensioning,Transportation
Our chains are made of selected steel material. We provide the chains with the best quality and the most reasonable price.
According to different applications and functions, chains are divided into transmission chains, conveyor chains, lifting chains and special chains.
1. transmission chain
Mainly used for transmitting power. For example, double pitch transmission roller chain, sleeve transmission chain, toothed transmission chain,etc.
2. Conveyor Chain
Chains mainly for transportation of materials. For example, long pitch conveyor chains, short pitch roller conveyor chains and so on.
3.Lifting Chains
Mainly used for tensioning and lifting machineries and cargos.
4. the Special Chains
Mainly used on special mechanical devices, with special features and structure chain.
| Product | TRANSPORT CHAIN ASTM80(G70) | |
| Place of origin | Shandong,China | |
| Brand Name | Sail Rigging | |
| Model Number | TRANSPORT CHAIN ASTM80(G70) | |
| Material | Carbon Steel | |
| Surface | Self-color, E.Galv. , H.D.Galv. | |
| Technology | Forging&Casting | |
| Size | AS Standard or Customers' Requirements | |
| Packing | Gunny bags,Cartons,Reels,Pails,Drums,Ply-wood Boxes | |
| Certification | ISO, SGS,CE | |
| Using for | Lifting,Tensioning,Transportation | |
Technique parameter:
| TRADE SIZE | MATERIAL DIAMERTER | WORKING LOAD LIMIT | PROOF TEST | BREAKING FORCE MINIMUM | MAX LENGTH PER 100 LINKS | MAX WEIGHT PER 100 FEET | ||||||
| IN | MM | LBS | KG | LBS | KN | LBS | KN | IN | M | LBS | KG | |
| 1/4 | 0.281 | 7.1 | 3150 | 1430 | 6300 | 28 | 12600 | 56 | 98 | 2.5 | 84 | 38 |
| 5/16 | 0.343 | 8.7 | 4700 | 2130 | 9400 | 41.8 | 18800 | 84 | 110 | 2.8 | 120 | 54 |
| 3/8 | 0.406 | 10.3 | 6600 | 3000 | 13200 | 58.7 | 26400 | 117 | 134 | 3.4 | 176 | 80 |
| 1/2 | 0.531 | 13.5 | 11300 | 5130 | 22600 | 100.5 | 45200 | 201 | 160 | 4.1 | 300 | 136 |
