RF application sma female right angle pcb rf connector
- 10000 Piece / Pieces per Month
- Hongkong
- Credit Card
-
SMA bulkhead Female Right angle Connector for PCB
-
sma connector for tv antenna,4 hole flange connector
-
SMA Connector ,flange connector
-
SMA RIGHT ANGLE FEMALE RF COAXIAL CONNECTOR pcb mounting crimp connector
-
SMA female with bulkhead for rg316 cable
-
SMA jack female waterproof bulkhead connector for RG316 RG174 LMR100 cable
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | SH-Link | Model Number: | SHM.030.036 SMA-KWE-8 |
| Type: | SMA | Application: | RF | Gender: | Female |
Product Description
SMA Coaxial Connectors
MAJOR TECHNICAL CHARACTERISTICS
Temperature range -55—+155℃(PE Cable -40—+85℃)
Vibration 98m/S²(10-2000Hz)10g
Impedance 50Ω
Frequency range DC-12.4GHz(Semi-Rigled Cable DC-18GHz)
Working voltage 335V r.m.s at sea level
Withstanding voltage 1000V r.m.s at sea level
Contact resistance
Center contact ≤3mΩ
Outer contact ≤2.5mΩ
Insulation resistance ≥5000MΩ
Center conductor retention force ≥0.28N
Coupling nut retention force ≥180N
Insertion loss ≤0.15dB/6GHz
Voltage Standing Wave Ratio
Straight ≤1.10+0.02f
≤1.07+0.018f
Right angle ≤1.20+0.03f
≤1.17+0.02f
Durability(mating) ≥500times(Cycles)
