Single Phase register display electricity energy meter

FOB Price

USD $4.50 - $6.00 / Piece

1000 Pieces(Min.Order)

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Main Features

Total forward active energy measurement

Number of digits value field Up to 6

Digit size 4x10mm

Technical parameters:

Electrical parameters:
Voltage
Nominal voltage Un	230V
Extended operating voltage range	80%~115%Un
Limited voltage	70%~120%Un
Frequency
Nominal frequency fn	60Hz
tolerance	5%
Current
Basic current(Ib)	10A
Maximum current(Imax)	100A
Starting current(Ist)	30mA
Active energy constant	1000imp/kWh
Measurement Accuracy
Active energy to IEC62053_21	Class1.0
Reactive energy to IEC62053_23	Class2.0
Power Consumption
Power consumption in Voltage circuit	<2W <8VA
Power consumption in current circuit	<1VA
Temperature range
Operation meter	25℃ to+70℃
Storage	40℃ to+85℃

Insulation strength
AC Insulation strength	4kV at 50Hz during 1min
Impulse voltage 1.2/50 μs mains connections	8kV

Electro Magnetic Compatibility
Electrostatic discharges
Contact discharge	8kV
Air discharge	16kV
Electromagnetic RFfields
27MHz to 500MHz typical	10V/m
100kHz to 1GHz typical	30V/m
Fast transient burst test	4kV

Mechanical requirements
Meter shell Protection Rate	IP54
Protection	classII
