ET-1 load cell
- 300 Set / Sets per Month
- Shanghai China;Ningbo China
- T/T
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | Everight | Model Number: | ET-1 |
| Usage: | Pressure Sensor | Theory: | Resistance Sensor | Output: | Switching Transducer |
Product Description
Specifications
load cell1,manufacturer
2,anti-side load capability
3,compact structure
4,easy installation
load cell
The elastomer of ET-1 load cell is made from high quality alloy steel. High precision and good impact resistance; anti-side load capability; compact structure; easy installation.
Specifications
Output sensitivity | mV/V | 2.00 | |||
Nonlinearity | %FS | ≤0.03 | |||
Hysteresis | %FS | ≤0.03 | |||
Repeatability | %FS | ≤0.01 | |||
Zero balance | %FS | ≤1.00 | |||
Creep (in 30min) | %FS/30min | ≤0.02 | |||
Zero efficient | %FS/10°C | ≤0.04 | |||
Rated output efficient | %FS/10°C | ≤0.02 | |||
Input resistance | Ω | 385±10 | |||
Output resistance | Ω | 350±3 | |||
Insulation resistance | MΩ | ≥5000 | |||
Safe overload | %FS | 150 | |||
Compensated Temp.range | °C | -10~+40 | |||
Recommended Supply voltage | V | 5~15 | |||
4-Core shield cable 3 m | Input | +: Red | -:Black | ||
Output | +:Green | -:White | |||
Shield | Yellow or Bare | ||||
Warning: It will affect the function of sensor to change the cable’s length!
