SC 1325 130W co2 laser sheet metal cutting machine with CE FDA
Machine Introduction :
1. Laser cutting bed, suitable for large size nonmetal materials processing.
2. Very stable 3 phases stepper motor.
3. RECI brand laser tube---80W, 100W, 150W, 180W, which is very good for cutting work.
4. Imported focus lens and reflecting mirrors.
5 HIWIN Linear Rail, durable rubber belt, which can assure high cutting precision.
Applicable industries:
Advertisement, furniture, leather, shoemaking, decoration ,packing and printing, molding and art craft industries.
Technical Parameter:
S/L-1325 Laser Cutting Machine | |
Model NO. | S/L-1325 Laser Cutting Machine |
Machine Dimension | 308cm*200cm*112cm |
Cutting Area | 1300x 2500mm |
Laser Power | RECI 130W/150W |
Laser Type | CO2 Laser Tube |
Cutting Speed | 0 -50000mm/min |
Reposition Accuracy | ±0.01mm |
Power Supply | AC 220V, 50HZ or 110V, 60HZ |
Operation Temperature | 0 - 45°C |
Operation Humidity | 5 - 95% |
Min. Shaping Character | Character 2*2mm, English 1 x 1mm |
Graphic Format Supported | PLT, DXF, BMP, AI, DST |
Software Supported | CorelDraw, Photoshop, AutoCAD |
Driving System | Stepper or Servo Motor |
Cooling Mode | Water-cooling and Protection System |
Optional Spare Parts | Red Light Pointer |
Recommended Spare Parts | Laser Tube and Lens |
Net Weight/Gross Weight | 530KGS/550KGS |
Packing Dimension | 3440X1870X1180mm |
Machine details:
Samples:
Sinmic Machinery was founded in 2005 as a machinery service company, primarily servicing, selling and installing CNC machinery including several brands of CNC routers.
Now Sinmic design and manufacture CNC routers and laser machine for many industries, enabling our customers to efficiently produce a wide range of products.
Certificate:
With customers:
A.we offer 2 years warranty for whole machine
B. for laser tube: 40w-for 5 months
60w -for 6months
RECI 80W, 100W,150W,180W-for 10 months
--this is what laser tube supplier offer to us.
C. for laser lens: for one month.
If the accessories are broken because of quality problems during warranty time, you can send back to us, we will repair and send back to you freely.
D. 24hours technical support will be supplied when you need
