Specifications
PVC compounding machine1. Mainly for: PVC powder+CaCO3 mixing.
2. CE/ISO
3.high quality
PVC compounding machine
Part I Summary description:
PVC mixer (PVC mixer machine/PVC powder mixer) is special for PVC+CACO3 mixing. It with high qualtiy and long use life.This unit puts the hot mixer and cold mixer together making the mixed hot material into the coling mixer automatically and exaust the left gas in the material in case the material agglomeration.
Part II Technical parameter of PVC mixer (PVC mixer machine/PVC powder mixer)
Model | SRL-Z50/100A | SRL-Z100/200A | SRL-Z200/500A | SRL-Z300/60000A | SRL-Z500/1000A |
Total capacity | 50/100 | 100/200 | 200/500 | 300/600 | 500/1000 |
Effective Capacity | 37/70 | 75/130 | 150/320 | 225/360 | 375/360 |
Speed | 650/1300/118 | 650/1300/130 | 475/950/130 | 475/950/130 | 375/750/640 |
Motor power | 7/11/7/5Kw | 14/22/11 | 30/42/11 | 40/55/11 | 55/75/15 |
Heating power | 3 | 3 | 6 | 6 | 9 |
Cooling method | Water cooling | ||||
Material discharging method | Pneumatic | ||||
