power tool,1'' air impact wrench, tools,pneumatic tools

Specifications

1,pin-less hammer
2,1"air impact wrench
3,pneumatic tools
4,power tools
5,air tools

1"air impact wrench

* Handle exhaust or front exhaust or side exhaust
* High performance pin-less  hammer mechanism
* Easy adjustable power regulator /power switch. High torque
*  Ideal Tools for high volume tire work on buses , trucks and other heavy equipment.
   suitable for high volume trucks spring, truck  maintenance and heavy equipment shops.


Product Parameter



Model: ZM-100L  1"PIN-LESS HAMMER

1.Free Speed 3300r.p.m                                                                                                                                            2.Max.Torque                4180N.M

 3.Air    Inlet              1/2"                                                                                                                                             4.Net       Weight 20Kg                                                                                                                                                                   5.Anvil      Length         8"                                                                                                                                                       6.Air Pressure 6-10kg





Service Instructions



This Brand Pneumatic Spanner is made of  wear-resistant and shockproof materials under excellent design and strict quality control.

Notes to the users before operating:

1. Keen dry and clean of air cylinder and gas container , and be sure that the air supply tube shall no be air leakage.
2. Check to see if the air gauge is at 10KG, safety standard level within 7.8 KG of working pressure.
3. In order to keep normal operation of this unit , be sure to fill in the air and water from air outlet of air cylinder, filter, and auto oil filter combination. Refer to the picture one.
4. If no oil filter, pleasure fill oil in according to the assigned oil port. Fill oil in before working to keep the best performance function of this unit.(Pleasure use of recommended oil or spindle oil for pneumatic spanner.)
5. If this unit keeps still without running or suns not smoothly, please use of large capacity of special recommended oil or spindle oil to fill in for pneumatic spanner turning. Remove and clean away the dirt and obstacles . if they are unable to be removed after continuous twice or three times, pleasure send them to the dealer for repair or maintenance.
