Home > Products > Passenger Elevator > Luxury passenger elevator
Luxury passenger elevator
- 200 Set / Sets per Month
- Shanghai
- T/T
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | general brand | Model Number: | Elevators |
Usage: | Residential Elevators | Drive Type: | AC, Hydraulic | Elevator Type: | Passenger Elevators |
Product Description
Passenger elevator incorporates state-of-the-art permanent magnet synchronous technology that
contributes to a compact structure of traction machine; additionally, VVVF serial control technology
provides elevators with an ergonomic operating curve as well as smooth and low-noise operation.
The control system is incorporates highly reliable microcomputer serial communication technology for rapid signal response and excellent immunity.When compared with traditional elevators with machine room, small machine room elevator employs more rational civil layout that contributes to less space occupation and lower construction cost.
Elevators are furnished with international leading permanent magnet sychronous gearless traction
machine that features low noise, less conspicious vibration, high system, efficiency and low energy consumption, thereby avoiding environmental pollution that may arise from the use of gear oil in traditional traction machine.
The introduction of cutting-edge VVVF control technology ,precision reducer and all- digital pulse
width modulation control device and the load-dependent automatic adjustment of elevator startup
torque guarantee the more smooth acceleration and deceleration of elevator.
Rated Load | Persons | Drag Method | Rated Speed | Net Dimension of Car | Dimension of Door Opening | Dimension of Hoistway | Over Head | Pit Depth | |||
Width | Depth | Width | Height | Width | Depth | ||||||
KG | Num |
| m/s | Unit:mm | |||||||
450 | 6 | V V V F | 1.0 | 1400 | 850 | 800 | 2100 | 1900 | 1500 | 4300 | 1400 |
630 | 8 | 1.0/1.5/1.75 | 1400 | 1100 | 800 | 2100 | 1900 | 1700 | 4300/4500/4600 | 1400/1600/1600 | |
800 | 10 | 1.0/1.5/1.75/2.0 | 1400 | 1350 | 800 | 2100 | 1900 | 2000 | 4300/4500 4600/4900 | 1400/1600 1600/2100 | |
1000 | 13 | 1.0/1.6/1.75/2.0 | 1600 | 1500 | 900 | 2100 | 2200 | 2150 | 4300/4500 4600/4900 | 1400/1600 1600/2100 | |
1250 | 16 | 1.0/1.6/1.75/2.0 | 1950 | 1400 | 1100 | 2100 | 2600 | 2100 | 4500/4600 4600/4900 | 1500/1600 1700/2200 | |
1600 | 21 | 1.0/1.6/1.75/2.0 | 1950 | 1750 | 1100 | 2100 | 2600 | 2600 | 4500/4600 4600/4900 | 1500/1700 1700/2200 |
