Home > Products > Four-column hydraulic cutting machine > zhicheng Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers

zhicheng Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers

Name: zhicheng Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers
Brand: zhicheng
Availability: InStock

FOB Price

USD $4,000 - $5,000 / Set

1 Set(Min.Order)

Supply Ability 80 Set / Sets per Month
Port shanghai ningbo qingdao (plastic die cutting machine manufacturers)
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	zhicheng	Model Number:	ZC-509-40T
Machine Type:	Other, die cutting machine	Type:	Other, die cut plastic die cutting machine manufacturers	Use:	Other, die cutting machine for cloth

Product Description

ZC-509-40T Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers

Company Detail

Our company is professional on manufacturing shoemaking machinery with 25 years history, located in the world's footwear production in manufacturing city base-- yancheng, Jiangsu, with the integration of R&D, manufacturing and sales, also own the modern management , have the continue developing and innovation in shoe making machinery and rubber, EVA sole making machinery.

Our company has a complete rubber making machinery. moreover, our machine sold to 60 countries in the world. Perfect after-sales service and high quality machine could be offered by our factory.

Machine Description

What Specification of our cutting press?

The working principle of the hydraulic cutting machine is down press to the mould,to cut material by dies / moulds.

1,The doubie oil cylinder and precise four-column automatic balancing mechanism can make the cutting depth withimn the cutting area even.
2,With stable pressure,there will be no occurrence of cutting failure or edge burr.
3,It can accurately align with the cutting board to prevent the plastic cutting board from sticking onto finished products.
4,The tow-section trpe cutting can solve the radian problem met during the cutting of pearl cotton,spong and other materials of multiple layers.

Mainly used for die cutting leather and leather

products,plastic,rubber,sponge,foam,EVA,PVC,cardboard, paper products,fabric,home textiles,packaging materials,non woven,carpet,car cushion,felt,synthetic materials, and other non-metallic materials in various industries;Extremely suitable for cutting multiple layers of material at one time.

25 years experience of cutting press machine

1. Technical Parameters

Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers

Model	Cutting Force	Dimension *(LWH)*	Cutting Area	Motor Power	Stroke	Net weight
ZC-509-30T	30Tons	1780x1000x1350mm	1250x500mm	3HP	50~180mm	1400kg
ZC-509-30T	30Tons	2050x1000x1350mm	1470x500mm	3HP	50~180mm	1500kg
ZC-509-30T	30Tons	2180x1000x1350mm	1600x500mm	3HP	50~180mm	1700kg
ZC-509-40T	40Tons	1830x1200x1420mm	1250x610,710mm	5HP	50~180mm	1700,1800kg
ZC-509-40T	40Tons	2100x1200x1420mm	1470x610,710mm	5HP	50~180mm	1800,2000kg
ZC-509-40T	40Tons	2230x1200x1420mm	1600x610,710mm	5HP	50~180mm	2000,2200kg
ZC-509-50T	50Tons	1880x1300x1520mm	1250x800mm	8HP	50~240mm	2500kg
ZC-509-50T	50Tons	2150x1300x1520mm	1470x800mm	8HP	50~240mm	2800kg
ZC-509-60T	60Tons	2280x1300x1520mm	1600x800mm	8HP	50~240mm	3000kg

2.Customer use of the site

2. Features and Advantages

Features and Advantages( Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers )

1. Digital control system of “PLC+coder”human-machine interface is adopted to realize automatic feeding,patten arrangement and cutting times with high precision. The positioning precision can reach 0.2mm so as to save materials,enhance work efficiency and reduce labor intensity.

2. PLC program control center is provided with memory function for the settings of operation instructions,which are not influence in case of power failure or power-cut after work,so as to facilitate operation for the next time.

3. Double oil cylinders drive,four-column guiding and automatic balancing are adopted to guarantee identical cutting depth for each time.

4. Three operation modes such as automatic,semiautomatic and manual operations are optional,which are free and flexible.

5. The cutting head can carry out automatic transverse movement and automatic positioning. The die cutter is fixed by electromagnetic suction disc. Without the need of setting die cutters,the upper and lower die cutters can carry out cutting freely with connivent operation.

6. The automatic lubricating system ensures machine precision and prolongs service life.

Mass Produced products

We can according to your material,requirements,design the machine and mould for you.

3.Application:

The hydraulic cutting press machine is suitable to die cut Footwear factory, shoe materials factory, bag factory , leather goods factory, rubber conveyor belt, PVC conveyor belt, EVA foaming, PVC foaming, rubber products, beach shoe forming, vamps, sport shoe, and so on

4.the cutting machine Workshop Show

5. Our Certifications

Hydraulic Plastic Gift Boxes Die Cutting Machine Manufacturers

1. We are a factory,and the price is favorable.

2. We have strict QC system.

3. We offer a free after-sales service for 1.5 years.

4. Our engineers are available to service machinery overseas.

5. Our machines have been sold to over 60 countries.

Payment & Shipping

Trade term:FOB,CIF,EXW

Payment terms:T/T,Westem Union,PayPal,Escow,MoneyGram.

Payment Condition:30% deposit in advance. 70% balance before delivery.

Delivery time:5-15days working days after deposit.

Packing:Wooden case with plate.

Shipment:By Sea.

6.Trade shows

Note: we can produce different types, tons and cutting area of machine according to your demand.

Why choose us?

Check below for more information on placing an order

1. Inquiry-Professional quotation.

2. Confirm the price, lead time, artwork, payment term etc.

3. zhicheng sales send the Proforma Invoice.

4. Customer make the payment for deposit and send us Bank receipt.

5.Initial Production Stage-Inform the clients that we have got the payment,And will make the samples according to your request, send you photos or Samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time.

6. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.

7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party Inspection .

8. Clients make payment for balance and zhicheng Ship the goods. Inform the tracking number and check the status for clients.

9. Order can be say “finish” when you receive the goods and satisfy with them .

10. Feedback to Freedom about Quality , Service, Market Feedback & Suggestion. And we can do better .

Guarantee and after-sale service

* One year guarantee.

* 24 hours technical support by e-mail.

* Calling or door-to-door service. Seller can send the engineer to buyer’s factory, but Buyer shall pay the round-trip air fare and accommodation

* Offer user manual and videos.
