Automatic Soda Drink Filling and Capping Machine (3-in-1)

Specifications

1.Model: WT12-12-6,WT16-16-5,WT18-18-6.WT-32-32-8

2.Capacity: 3000-15000BPH (500ml PET standard bottle)

3.Material: The material which contact directly with the liquid is the SUS304 (Food grade), made in china.The 3-in-1 is mainly used

to fill pure water, Mineral water.milk, wine and so on.

4.It adopts bottle-neck hanging technology,not only avoiding second pollution to the bottle neck, but also realizing to fill different specs of bottles in one equipment, which greatly

improved commonality of this equipment.

5.Spring cramps are used in the bottle washing process.The empty bottle can be turned over 180 degree for washing.

6.Adopts Magnetic torque to realize screw capping, it can be adjusted without stepless,the screw capping power will be fixed, caps will not be damaged, and meantime it can get good cap

sealing.

7.The whole machine is controlled by PLC touch screen and human-machine interface.The storage tank liquid can be controlled automatically.If no bottle, no filling, no bottle no capping.The frequency technology is used to adjust the operation speed steplessly.The capacity will be showed on the human-machine interface, workers can adjust it according to their requirement.

Main parts configuration:

1)Transducer: Japan Mitsubishi

2)Touch screen :Taiwan Delta

3)AC contactor: Schneider

4)Electric parts :Schneider

5)Cylinder China Taiwan Airtac

6)Power switch: Schneider

7)PLC: Japan Mitsubishi

8)Electricity appliance: SIEMENS

Main Technical Specifications (500ml):

1)Model: WT16-16-5 WT18-18-6 WT24-24-8

2)Production(b/h): 5000 8000 10000

3)Washing heads: 16 18 24

4)Filling heads: 16 18 24

5)Capping heads: 5 6 8

6)Suitable bottle shape: Circular or square

7)Bottle diameter(mm): Φ50-φ100

8)Bottle height(mm): 150-320

9)Washing medium: Aseptic water

10)Washing water's pressure(MPa): 0.25

11)Total output (KW): 3
