High speed carbon steel wire Drawing Machine/descaling machine/wire coiler machine/nail wire making machine

Specifications

Brand Name: wandeshun
Model Number: LT
Main Market: Asia, south America,MiddleEast,Africa



Specifications

1) Min. order: 1 set
2) Package details: as the normal export
3) Delivery time : 2 months
4) Payment terms: L/C T/T

Wire Drawing Machine/water tank Drawing machine/ Drawing Machine Factory





Drawing Machine Factory



----------------------------------------------



1. Feature of the drawing machine



The drawing machine applies advanced international technology,with digestion and absorption, the drawing machine id applicable for high intesity and performance demand. It mainly applied for the production of steel curtain wire,tyre steel wire ,steel wire for rope,spring steel wire ,stainless steel wire etc. The capston diameter of the straight line drawing machine series products is Φ350- Φ1200mm with maxium inlet diameter of Φ14mm and minimum outlet diameter of 0.7mm.







 The equipment of the straight line drawing machine contains the function of  human-machine dialogue,over tempertureprotaction for the moter,alarm for abnormal water pressure,fault display,ect. the capston appled the combination of the narrow water cooling and air cooling with good cooling effect. Generally it is an kind of efficient and advanced drawing wquipment with easy operation,high degree of automation and aboard process scope.





Main Technical Parameters





Equipment Model	LT160-23-260	LT160-21-275	LT320-17-360	LT320-15-360
Applicable Production	Zinc-plated/high-carbon steel wire	Resistance/Copper-coated steel wire	High-carbon/high-intensity steel wire	CO-protected welding wire
Drawing dies	23	21	17	15
Outlet range	0.1-0.5mm	0.15-0.5mm	0.5-1.0mm	1-1.6mm
Maximum speed	20m/s-1	18m/s-1	10m/s-1	8m/s1











About us

Wuxi Wandeshun Machine Co., Ltd. one of the leading wire drawing machine manufacturers in China , is specialized in manufacturing wire drawing machines , which was established in 2000.

Our products are popular in many provinces of china and have already been exported to Vietnam , Indonesia, Uzbekistan Kenya, South Africa,Algeria,Egypt, Iran,Turkey and so on.

Excellent geographic location and easy transportation access, only 2k meter from Wuxi airport and adjacent to national highway 312.Welcome friends of all industries to visit and instruct our factory.

Main products:   Straight line drawing machine

Water tank wire drawing machine

Aluminium wire drawing machines

Vertical wire drawing machine

Pulley wire drawing machine

We have a professional technical team, a good after-sale service team, an excellent production management team. We can design and produce various wire drawing machines, auxiliary equipment according to customers’ special requirements
