Home > Products > Silent Diesel generator > 5kva Diesel generator
5kva Diesel generator
Negotiable
/ Carton
2 Cartons(Min.Order)
- 3000 Carton / Cartons per Month
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Usage: | Automobile | Fuel: | Diesel | Stroke: | 4 Stroke |
| Cylinder: | Single Cylinder | Cold Style: | Other, Air-cooled | Start: | Electric Start |
| Place of Origin: | Jiangsu, China | Brand Name: | KOOP | Model Number: | KDF6700Q |
| Certification: | CE |
Product Description
| Model | KDF6700Q | | |
| Rated frequency (Hz) | 50 | 60 | |
| Rated voltage (V) | 220, 230, 240, 220/110, 230/115, 240/120 | ||
| Rated output power (KVA) | 4.2 | 4.5 | |
| Rated rotation speed (rpm) | 3000 | 3600 | |
| DC output | 12V, 7A | | |
| Power factor cosφ | 1 | | |
| Phase number | Single phase | | |
| Excitation mode | Self-excitation Brushless | ||
| Noise level dB(A)@ 7m (zero load - full load) | 70-74 | ||
| Overall dimension [mm(in)](L×W×H) | 920×520×700 | | |
| 36.22×20.47×27.56 | | ||
| Net weight [kg(lbs)] | 140 (308) | | |
| Structure model | Low noise type with enclosure | | |
| Connection mode | Single bearing, rotor drive shaft, rigid coupling | | |
| Engine model | KD186FE | | |
| Engine type | 1-cylinder, 4-stroke, air-cooled, direct injection, diesel engine | | |
| Displacement [cm³(Cu-in)] | 406 (24.78) | | |
| Compression ratio | 19:01 | | |
| Rated power [KW(Hp)/rpm] | 6.3 (8.6)/3600 | | |
| Starting system | Electric starting | | |
| Rotation direction (view from flywheel) | Clockwise | | |
| Fuel type | 0 (sumber), 10 (winter) diesel oil | | |
| Lube | SAE10W30 (above CC grade) | | |
| Low oil pressure alarm system | With | | |
